Product Information
PDR 908 HP [EL]
- Subject to technical changes; no liability accepted for the accuracy of the information given.
Product Information
Your advantages
Short program cycles
Quick and efficient
Honeycomb drum
Gentle care due to unique honeycomb drum structure
Low consumption values
Economical and efficient
PerfectDry system
Perfect drying results
Energy-saving heat-pump system*
Minimal energy consumption
Washer-dryer stack
Washing & drying on less than 5.38 sq.feet
M Touch Flex controls
The benchmark for modern user convenience
Intelligent dryers
Uniform drying results
Language can be selected easily at any time
Easy to understand
Drum lighting
Let there be light
Patented heat-exchanger filtration system*
High performance
Patented condensate drainage*
Simple drainage of condensed water
Washer-dryer stack
Washing & drying on less than 5.38 sq.feet
M Touch Flex controls
The benchmark for modern user convenience
Convenient lint filter*
Effective and easy to clean
Programmable dryer controls
Greater flexibility
Delay start up to 24 hours
Laundry care according to schedule
Countdown indicator
An eye on the time
Language can be selected easily at any time
Easy to understand
Low consumption values
Economical and efficient
Energy-saving heat-pump system*
Minimal energy consumption
Large capacity
More capacity for the best results
Excellent durability
Ultimate quality
Honeycomb drum
Gentle care due to unique honeycomb drum structure
Perfect Anti-crease
Wrinkle-free
Special drying basket
Gentle drying of textiles
SoftLift drum ribs ensure gentle fabric care
Take it with you
Short program cycles
Quick and efficient
PerfectDry system
Perfect drying results
Axial airflow
Outstanding drying results
Intelligent dryers
Uniform drying results
Connection of payment system
Self-service operation
Product data sheet
Design | Front-loader, stackable |
Linie | Performance Plus |
Front | Lotus White |
Control panel color | Stainless Steel |
Load in lbs.(kg) | 18 (8.0) |
Drum volume in ft³ (l) | 4.59 (130.00) |
Drying system | Heat pump |
Door opening [Ø] in in.(mm) | 14 5/8 (370) |
Door opening angle in degrees | 167 |
Door hinging | left |
Stainless steel honeycomb drum | • |
Suitable for the hotel and catering industry | • |
Suitable for retirement and care homes | • |
Suitable for facility management | • |
Suitable for launderettes | • |
Suitable for dry cleaners | • |
Suitable for commercial laundries | • |
Suitable for small businesses | • |
Suitable for universities, nurseries, and schools | • |
Suitable for hospitals | • |
Suitable for camp sites | • |
Suitable for sports clubs | • |
Suitable for beauty salons, spas and fit ness centers | • |
Suitable for doctors' and dentists' practices | • |
Suitable for the petrochemical industry | • |
Suitable for the food-processing industry | • |
Suitable for amusement parks and holiday complexes | • |
Suitable for public/community care facilities | • |
Maximum evaporation capacity in l/hour and gal. qts./hour | 3 (3) gal (US)/min (l) |
Specific energy consumption in kWh/kg an d kWh/p | 0.20 |
Specific energy consumption for cottons/Normal drying, residual moisture 48% in kWh/kg | 0.20 |
Specific energy consumption for mixed fabric/Normal drying, residual moisture 40% in kWh/kg | 0.17 |
Program cycle in min. | 88 |
Program cycle time for cottons/Normal drying, residual moisture 48% in min. | 88 |
Program cycle time for cottons/Normal drying, residual moisture 40% in min. | 76 |
Control system | M Touch Flex |
Programmability | programmable |
Program controls | Residual moisture controlled |
Max. delay start in h | 24 |
Countdown indicator | • |
Program sequence indicator | • |
Language can be selected easily at any time | • |
Type of heating | Heat pump |
Electrical connection | 2 AC 208-240V 60HZ |
Total connected load in kW | 1.20 |
Fuse rating in A | 30 |
NEMA plug: Twist Lock L6-30 | • |
External dimensions, net height in inches | 33 1/2 (850) |
External dimensions, net width in inches | 23 1/2 (596) |
External dimensions, net depth in inches | 30 5/8 (777) |
External dimensions, gross height in inches | 37 1/16 (940) |
External dimensions, gross width in inches | 26 (660) |
External dimensions, gross depth in inches | 32 5/16 (820) |
Net weight in lbs. (kg) | 157 (71.0) |
Gross weight in lbs. (kg) | 170 (77) |
Maximum floor load in N | 920 |
Emissions - sound pressure at workplace | <lt/>70 dB(A) re 20 µPa |
Heat output to the room in Mj/h and BTUs /h | 3.60 |
Intelligent drum reversal | • |
Axial airflow | • |
Fluff filter in the door | • |
Low-maintenance heat exchanger filter system | • |
PerfectDry | • |
SoftLift drum ribs | • |
Gentle tumble function | • |
Condensed water drainage | • |
Communication slot | • |
Drying basket (optional) | • |
Drum lighting | • |
Machine-independent accessories | • |
Recycling rate in % | 95 |
Contains fluorinated greenhouse gases | • |
Hermetically sealed system | • |
Coolant | R134a |
Refrigerant quantity in kg | 0.59 |
Refrigerant global warming potential in kg CO2e | 1430 |
Appliance global warming potential in kg CO2e | 844 |
Payment system (optional) | • |
Optical interface for service access | • |
WEEE | • |
c ETL US | • |
Optional products and accessories
- Product sheetPDF
- Installation planPDF
- Operating instructions/Installation instructionsPDF
- Operating instructions/Installation instructionsPDF
- Warranty conditionsPDF
- Product datasheetPDF
Follow the link and you will find all the resources you need for planning and installing any of our products
- rfaZIP
- dwgZIP
- rvtZIP
- fbxZIP
- ifcZIP
Follow the link and you will find all the resources you need for planning and installing any of our products
- 1.The heat pump contains fluorinated greenhouse gases in a hermetically sealed system.
- 2.European patent: EP2532779
- 3.German patent: DE102013104124
- 4.European patent: EP2273005
- 5.German patent: DE 10 2018 104 694 B3/European patent: EP2107155
- Subject to technical changes; no liability accepted for the accuracy of the information given.
