Product Information
Inside the Box
- Anti-splash insert (1)
- Self Clean ready baking and roasting rack (2)
- Self clean ready baking and roasting racks with rail system (1)
- Side racks self clean ready (1)
HR 1936-3 LP DF GD
- Subject to technical changes; no liability accepted for the accuracy of the information given.
Product Information
Inside the Box
- Anti-splash insert (1)
- Self Clean ready baking and roasting rack (2)
- Self clean ready baking and roasting racks with rail system (1)
- Side racks self clean ready (1)
Your advantages
Moisture Plus
Added moisture for optimal results.
ComfortSwivel Handle
Perfect ergonomic design
Rapid PreHeat
Your guarantee for perfect results
Self Clean Oven and Self Clean Ready Accessories
Treat yourself to minimum effort
Appliance networking with Miele@home*
Cleverly networked
AirCleanCatalyzer
Removes odors and grease from cooking vapours
ComfortClean Dishwasher-Safe Grates
Efficiently protects and makes cleaning easier
Self Clean Oven and Self Clean Ready Accessories
Treat yourself to minimum effort
Clean Touch Steel™Front
Protection for immaculate stainless steel surfaces
ComfortSwivel Handle
Perfect ergonomic design
Individual settings
Appliance configuration according to your wishes
Timer Function
Leave time management to your oven
Soft Open and Soft Close
Everything is well thought through
Favorites
Save frequently used settings
Appliance networking with Miele@home*
Cleverly networked
Moisture Plus
Added moisture for optimal results.
Crisp function
Targeted moisture reduction in compartment
Residual Heat Utilization
Conserve heat and energy
Rapid PreHeat
Your guarantee for perfect results
TwinPower Convection Blowers and Power Convection Blower
Reaches the desired temperature very quickly
Cooling System and Cool-Touch Fronts
Pleasantly cool surfaces
Safety functions
Automatic switch-off for maximum safety
Surround
Moisture Plus
Intensive
Auto Roast
Convection Roast
Bake
Maxi Broil
Broil
Browning
Slow Roasting
Special Modes
Sabbath
Crisp function
Favorites
Defrosting
Convection Bake
Convection Roast
Product data sheet
Dual fuel | • |
Gas type | Liquid propane |
Range | • |
Appliance width in inches | 36 |
Defrost | • |
Speed oven automatic programs | • |
Auto roast | • |
Maxi Broil | • |
Broil | • |
• | |
• | |
Intensive | • |
Moisture plus | • |
Slow roast | • |
Surround | • |
Browning | • |
Bake | • |
Convection Roast | • |
Special modes | • |
Appliance color | Clean Touch Steel |
Oven display | M Touch |
Wireless Precision Probe | • |
Keep-warm function | • |
Crisp function | • |
Number of gas burners | 4 |
Number of TrueSimmer burners x power in BTU | 1 x 12 500 BTU/hod. |
Number of power burners x power in BTU | 1 x 13.000 |
Number of high burners x power in BTU | 2 x 19.500 |
True Simmer function | • |
GasStop | • |
Number of griddle surfaces | 1 x 14.300 |
Width of griddle surface in in.(mm) | 10 1/4 (258) in (mm) |
Depth of griddle surface in in.(mm) | 17 1/8 (434) in (mm) |
• | |
Precision knobs | • |
Illuminated knob | • |
ComfortSwivel handle | • |
Motorized lift-up control panel | • |
Sabbath program | • |
MultiLingua | • |
MyMiele | • |
Time synchronization | • |
Time of day display | • |
Date display | • |
Minute minder | • |
Automatic switch-off | • |
Programmable cooking time | • |
Actual temperature display | • |
Default temperatures | • |
Acoustic signal when desired temperature is reached | • |
Favorites | Yes |
Individual settings | • |
Timed bursts of steam | • |
CleanGlass door | • |
Door contact switch | • |
SoftClose oven door/ SoftOpen | • |
Oven cavity volume in cu. ft. (l) | 5.76 (163) ft³ (l) |
Number of oven shelf levels | 6 |
No. of halogen lamps | double |
TwinPower hot air fans | • |
Energy-saving lighting circuit | • |
Residual heat utilization | • |
Rapid PreHeat | • |
Stainless-steel front with partial Clean Touch Steel finish | • |
Oven with self-cleaning program | • |
AirClean catalyzer | • |
heated | |
ComfortClean dishwasher-safe grates | • |
Cooktop surface | Black enamel |
Appliance cooling system with cool touch front | • |
Safety cut-out | • |
System lock | • |
Door contact switch | • |
Door lock during self cleaning | • |
Appliance width in inches | 35 15/16 |
Appliance width in in.(mm) | 36 1/8 (915) |
Appliance height min in in.(mm) | 37 1/8 (942) |
Appliance height max in in.(mm) | 38 5/8 (980) |
Appliance depth in in. (depth) with bullnose | 27 3/4 (702) |
Power Rating in V | 120 |
Convertible voltage in V | 240/208 |
Fuse rating in A | 40 |
Number of phases | 1 |
Fresh water connection for Moisture Plus | • |
Plumbed water connection for Moisture Plus | 1.50 |
Optional products and accessories
- Operating and Installation instructionsPDF
- Operating and Installation instructionsPDF
- Warranty conditionsPDF
- Product sheetPDF
Follow the link and you will find all the resources you need for planning and installing any of our products
- fbxZIP
- dwgZIP
- rfaZIP
- rvtZIP
- ifcZIP
Follow the link and you will find all the resources you need for planning and installing any of our products

HR19x4, HR193x, HR195x (installation drawing)
(x) = Toe-kick height adjustment 5" - 6 1/2" (127 mm - 165.1 mm)

HR1936G, HR1936-2, HR1936-3 (installation drawing)
E = Electric Connection
W = Water connection
G = Gas connection

HR11xx, HR19xx, HR 17xx - Installation drawing
1 Anti-tip device
2 Screws
3 Locking nut

HR11xx, HR19xx - Installation drawing
1 Anti-tip device
2 Screws
3 Locking nut

HR11xx, HR19xx, HR17xx - Installation drawing
1 Anti-tip device
2 Screws
3 Locking nut

HR11xx, HR19xx, HR17xx - Installation drawing
X 3 13/16" (97 mm): HR1124
HR1134
HR1135
HR1136
HR1724
HR1924
HR1934
HR1935
HR1936
HR1954
HR1955
HR1956
X 3 1/4" (82 mm): HR1134-2
HR1134-3
HR1135-2
HR1135-3
HR1136-2
HR1136-3
HR1924-2
HR1924-3
HR1934-2
HR1934-3
HR1935-2
HR1935-3
HR1936-2
HR1936-3
HR1954-2
HR1954-3
HR1955-2
HR1955-3
HR1956-2
HR1956-3

HR11xx, HR19xx, HR17xx - Installation drawing
A = Distance between the rear of the range to the supporting wall

HR19xx - Installation drawing
① Maximum depth of top cabinet
② Minimum distance to bottom edge of top cabinet
③ Distance from the floor to cooktop surface
④ Minimum distance to combustible surfaces
E = Electric connection
W = Water connection
G = Gas connection
(A) Width of cabinet opening
(B) Minimum distance between the top of the cooking area and the bottom of an unprotected combustible surface. Minimum distance to a protected combustible surface or when a Miele Ventilation Hood is installed. For all other Hoods please consult the manufacturer's specifications for required distances.
(C) Maximum connection width right and left
(D) Maximum connection height
(E) Maximum connection depth

HR11xx, HR19xx, HR17xx - Installation drawing
1 Opening in the range housing
2 Bolt of the anti-tip device
3 Locking clamp with slot

HR11xx, HR19xx, HR17xx - Installation drawing
1 Toe kick cover
2 Locking clamp

HR1924-3, HR1934-3, HR1935-3, HR1936-3, Side view, installation drawing
(x) = Toe-kick height adjustment 5” - 6 1/2” (127 mm - 165.1 mm)
