HR 1935-3 G DF GR
$13,199.00
Find a dealer

Product Information

36 inch range – the Dual Fuel all-rounder with M Touch for the highest demands.
  • Network-enabled WiFi appliance – Miele@home
  • Maximum variety - four powerful burners and a grill
  • Perfect baking and roasting results - Moisture plus
  • Ergonomic and easy operation - motorized lift-up control panel
  • Precise cooking temperature – Wireless Precision Probe

Inside the Box

  • Anti-splash insert (1)
  • Self Clean ready baking and roasting rack (2)
  • Self clean ready baking and roasting racks with rail system (1)
  • Side racks self clean ready (1)

HR 1935-3 G DF GR

36 inch range – the Dual Fuel all-rounder with M Touch for the highest demands.
  • Subject to technical changes; no liability accepted for the accuracy of the information given.

Product Information

36 inch range – the Dual Fuel all-rounder with M Touch for the highest demands.
  • Network-enabled WiFi appliance – Miele@home
  • Maximum variety - four powerful burners and a grill
  • Perfect baking and roasting results - Moisture plus
  • Ergonomic and easy operation - motorized lift-up control panel
  • Precise cooking temperature – Wireless Precision Probe

Inside the Box

  • Anti-splash insert (1)
  • Self Clean ready baking and roasting rack (2)
  • Self clean ready baking and roasting racks with rail system (1)
  • Side racks self clean ready (1)

Your advantages

Features depend on model – images are only examples and used for explanation purposes

Product data sheet

Dual fuel
Gas typeNatural gas
Range
Appliance width in inches36
Defrost
Speed oven automatic programs
Auto roast
Maxi Broil
Broil
Intensive
Moisture plus
Slow roast
Surround
Browning
Bake
Convection Roast
Special modes
Appliance colorClean Touch Steel
Oven displayM Touch
Wireless Precision Probe
Keep-warm function
Crisp function
Number of gas burners4
Number of TrueSimmer burners x power in BTU1 x 12 500 BTU/hod.
Number of power burners x power in BTU1 x 13.600
Number of high burners x power in BTU2 x 19.500
True Simmer function
GasStop
Number and power rating of grill surface in BTU/h1 x 19,000
Width of broil surface in in.(mm)11 1/4 (284) in (mm)
Depth of broil surface in in.(mm)22 1/8 (560) in (mm)
Precision knobs
Illuminated knob
ComfortSwivel handle
Motorized lift-up control panel
Sabbath program
MultiLingua
MyMiele
Time synchronization
Time of day display
Date display
Minute minder
Automatic switch-off
Programmable cooking time
Actual temperature display
Default temperatures
Acoustic signal when desired temperature is reached
FavoritesYes
Individual settings
Timed bursts of steam
CleanGlass door
Door contact switch
SoftClose oven door/ SoftOpen
Oven cavity volume in cu. ft. (l)5.76 (163) ft³ (l)
Number of oven shelf levels6
No. of halogen lampsdouble
TwinPower hot air fans
Energy-saving lighting circuit
Residual heat utilization
Rapid PreHeat
Stainless-steel front with partial Clean Touch Steel finish
Oven with self-cleaning program
AirClean catalyzer
Heated
ComfortClean dishwasher-safe grates
Cooktop surfaceBlack enamel
Appliance cooling system with cool touch front
Safety cut-out
System lock
Door contact switch
Door lock during self cleaning
Appliance width in inches35 15/16
Appliance width in in.(mm)36 1/8 (915)
Appliance height min in in.(mm)37 1/8 (942)
Appliance height max in in.(mm)38 5/8 (980)
Appliance depth in in. (depth) with bullnose27 3/4 (702)
Power Rating in V120
Convertible voltage in V240/208
Fuse rating in A30
Number of phases1
Fresh water connection for Moisture Plus
Plumbed water connection for Moisture Plus1.50

Optional products and accessories

Downloads, CAD, & apps
  • Product sheet
    PDF
  • Warranty conditions
    PDF
  • Operating and Installation instructions
    PDF
  • Operating and Installation instructions
    PDF

Follow the link and you will find all the resources you need for planning and installing any of our products

  • fbx
    ZIP
  • ifc
    ZIP
  • dwg
    ZIP
  • rvt
    ZIP
  • rfa
    ZIP

Follow the link and you will find all the resources you need for planning and installing any of our products

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorized experts. In the event of queries, please call us for some no-obligation advice!
Descriptions

HR1935G, HR1935-2, HR1935-3 (installation drawing)

E = Electric Connection

W = Water connection

G = Gas connection

Descriptions

HR19x4, HR193x, HR195x (installation drawing)

(x) = Toe-kick height adjustment 5" - 6 1/2" (127 mm - 165.1 mm)

Descriptions

HR11xx, HR19xx, HR 17xx - Installation drawing

1 Anti-tip device

2 Screws

3 Locking nut

Descriptions

HR11xx, HR19xx - Installation drawing

1 Anti-tip device

2 Screws

3 Locking nut

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

1 Anti-tip device

2 Screws

3 Locking nut

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

X 3 13/16" (97 mm): HR1124

HR1134

HR1135

HR1136

HR1724

HR1924

HR1934

HR1935

HR1936

HR1954

HR1955

HR1956

X 3 1/4" (82 mm): HR1134-2

HR1134-3

HR1135-2

HR1135-3

HR1136-2

HR1136-3

HR1924-2

HR1924-3

HR1934-2

HR1934-3

HR1935-2

HR1935-3

HR1936-2

HR1936-3

HR1954-2

HR1954-3

HR1955-2

HR1955-3

HR1956-2

HR1956-3

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

1 Toe kick cover

2 Locking clamp

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

A = Distance between the rear of the range to the supporting wall

Descriptions

HR19xx - Installation drawing

① Maximum depth of top cabinet

② Minimum distance to bottom edge of top cabinet

③ Distance from the floor to cooktop surface

④ Minimum distance to combustible surfaces

E = Electric connection

W = Water connection

G = Gas connection

(A) Width of cabinet opening

(B) Minimum distance between the top of the cooking area and the bottom of an unprotected combustible surface. Minimum distance to a protected combustible surface or when a Miele Ventilation Hood is installed. For all other Hoods please consult the manufacturer's specifications for required distances.

(C) Maximum connection width right and left

(D) Maximum connection height

(E) Maximum connection depth

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

1 Opening in the range housing

2 Bolt of the anti-tip device

3 Locking clamp with slot

Descriptions

HR1924-3, HR1934-3, HR1935-3, HR1936-3, Side view, installation drawing

(x) = Toe-kick height adjustment 5” - 6 1/2” (127 mm - 165.1 mm)

Monitor your Miele appliances while you are on the go.
With the Miele app for your smartphone or tablet you can now connect all your Miele appliances and benefit from its smart home features.
  • 1.Additional digital offer from Miele & Cie. KG. All smart applications are made possible with the Miele@home system. The range of functions can vary depending on the model and the country.
  • Subject to technical changes; no liability accepted for the accuracy of the information given.
