HR 1935-3 G DF GR
$13,199.00
Find a dealer
View in 360°View in AR

Product Information

36 inch range – the Dual Fuel all-rounder with M Touch for the highest demands.
  • Network-enabled WiFi appliance – Miele@home
  • Maximum variety - four powerful burners and a grill
  • Perfect baking and roasting results - Moisture plus
  • Ergonomic and easy operation - motorized lift-up control panel
  • Precise cooking temperature – Wireless Precision Probe

Inside the Box

  • Anti-splash insert (1)
  • Self Clean ready baking and roasting rack (2)
  • Self clean ready baking and roasting racks with rail system (1)
  • Side racks self clean ready (1)

HR 1935-3 G DF GR

36 inch range – the Dual Fuel all-rounder with M Touch for the highest demands.
  • Subject to technical changes; no liability accepted for the accuracy of the information given.

Product Information

36 inch range – the Dual Fuel all-rounder with M Touch for the highest demands.
  • Network-enabled WiFi appliance – Miele@home
  • Maximum variety - four powerful burners and a grill
  • Perfect baking and roasting results - Moisture plus
  • Ergonomic and easy operation - motorized lift-up control panel
  • Precise cooking temperature – Wireless Precision Probe

Inside the Box

  • Anti-splash insert (1)
  • Self Clean ready baking and roasting rack (2)
  • Self clean ready baking and roasting racks with rail system (1)
  • Side racks self clean ready (1)

Your advantages

Exclusive to Miele

Moisture Plus

Added moisture for optimal results.

Improved roasting and baking: moisture ensures an incredibly light dough and a nicely browned crust.
Discover more

ComfortSwivel Handle

Perfect ergonomic design

Convenient opening and closing: The ergonomic twist handle makes operating the appliance door easy.
Discover more

Rapid PreHeat

Your guarantee for perfect results

The All Gas Range allows for constant airflow resulting in quick preheat times, powerful bake and broil elements.
Discover more

Self Clean Oven and Self Clean Ready Accessories

Treat yourself to minimum effort

Less cleaning effort: The grease residue is broken down, helping to keep the oven and cooking accessories clean.
Discover more

Appliance networking with Miele@home*

Cleverly networked

Make your life smart: thanks to Miele@home you can cleverly network your domestic appliances – for more options.
Discover more
Features depend on model – images are only examples and used for explanation purposes

AirCleanCatalyzer

Removes odors and grease from cooking vapours

Reduces grease and odors and prevents deposits from collecting on furniture, walls and curtains.
Discover more

ComfortClean Dishwasher-Safe Grates

Efficiently protects and makes cleaning easier

Fast cleaning: Remove the pot rests and wash in the dishwasher. Fast clean-up with dishwasher-safe grates.
Discover more

Self Clean Oven and Self Clean Ready Accessories

Treat yourself to minimum effort

Less cleaning effort: The grease residue is broken down, helping to keep the oven and cooking accessories clean.
Discover more

Clean Touch Steel™Front

Protection for immaculate stainless steel surfaces

No fingerprints on stainless steel: surface has special finish which keeps clean without special cleaning agents.
Discover more

ComfortSwivel Handle

Perfect ergonomic design

Convenient opening and closing: The ergonomic twist handle makes operating the appliance door easy.
Discover more

Individual settings

Appliance configuration according to your wishes

You decide: Language, buzzer tones, display brightness and much more can be individually adjusted.
Discover more

Timer Function

Leave time management to your oven

Always on time: The start time, finish time and duration of the cooking process are easy to select.
Discover more

Soft Open and Soft Close

Everything is well thought through

The Range oven door effortlessly opens and closes, preventing the door from shutting or slamming.

Favorites

Save frequently used settings

For favorite dishes: Simply select operating mode, temperature and duration and save settings for repeated use.
Discover more

Appliance networking with Miele@home*

Cleverly networked

Make your life smart: thanks to Miele@home you can cleverly network your domestic appliances – for more options.
Discover more
Exclusive to Miele

Moisture Plus

Added moisture for optimal results.

Improved roasting and baking: moisture ensures an incredibly light dough and a nicely browned crust.
Discover more

Crisp function

Targeted moisture reduction in compartment

For a crispy finish: Some food is cooked better using dry heat, such as pizza or French fries.
Discover more

Residual Heat Utilization

Conserve heat and energy

Ecological and economical: Miele ovens turn off early and use residual heat to complete the cooking process.
Discover more

Rapid PreHeat

Your guarantee for perfect results

The All Gas Range allows for constant airflow resulting in quick preheat times, powerful bake and broil elements.
Discover more

TwinPower Convection Blowers and Power Convection Blower

Reaches the desired temperature very quickly

Quickly ready for use: 2 hot air blowers heat the oven very rapidly with optimum hot air distribution.
Discover more

Cooling System and Cool-Touch Fronts

Pleasantly cool surfaces

Maximum protection: All surfaces on and around the appliance remain cool and can be touched safely.
Discover more

Safety functions

Automatic switch-off for maximum safety

Your guardian angel: If you forget to switch off the appliance, the safety switch-off steps in for you.
Discover more

Surround

Multi-purpose, classic function: perfect results on all traditional baking and roasting dishes.

Moisture Plus

As if fresh from the baker: moisture ensures an incredibly light dough and a nicely browned crust.

Intensive

Crispy bases, tasty toppings: For pizza, quiche or flans, the base will be crispy, the topping will be moist.

Auto Roast

Meat stays tender: Meat is seared at a high temperature and cooked to perfection with individual temperatures.

Convection Roast

Crispy on the outside, succulent inside: Ideal for chicken, duck, joints, rolled meat and many other meat dishes.

Bake

Individual requirements: For dishes which need to be cooked in a bain marie or browned from below.

Maxi Broil

Versatile function for indoors: For grilling large quantities of steak, sausages, kebabs, etc.

Broil

Designed for small quantities: Ideal for small amounts of food such as steak and sausages. Perfect every time.

Browning

Perfect finish: The final touch - ideal for gratins, glazing and browning

Slow Roasting

For perfect results: With low temperatures, meat recipes automatically become specialities.

Special Modes

The ideal assistant for special tasks: for example thawing, dehydrating, heating up or quick pre-cooking.

Sabbath

Miele's unique Sabbath mode allows individuals up to 72 hours of pre-programmed cooking in their oven.

Crisp function

For a crispy finish: Some food is cooked better using dry heat, such as pizza or French fries.

Favorites

For favorite dishes: Simply select operating mode, temperature and duration and save settings for repeated use.

Defrosting

Gentle on frozen food: Frozen food is gently defrosted under ideal conditions using cool air.

Convection Bake

Perfectly soft and light: ideal for gentle baking on up to two levels.

Convection Roast

Perfectly soft and light: ideal for gentle roasting on up to two levels.

Product data sheet

Dual fuel•
Gas typeNatural gas
Range•
Appliance width in inches36
Defrost•
Speed oven automatic programs•
Auto roast•
Maxi Broil•
Broil•
•
•
Intensive•
Moisture plus•
Slow roast•
Surround•
Browning•
Bake•
Convection Roast•
Special modes•
Appliance colorClean Touch Steel
Oven displayM Touch
Wireless Precision Probe•
Keep-warm function•
Crisp function•
Number of gas burners4
Number of TrueSimmer burners x power in BTU1 x 12 500 BTU/hod.
Number of power burners x power in BTU1 x 13.600
Number of high burners x power in BTU2 x 19.500
True Simmer function•
GasStop•
Number and power rating of grill surface in BTU/h1 x 19,000
Width of broil surface in in.(mm)11 1/4 (284) in (mm)
Depth of broil surface in in.(mm)22 1/8 (560) in (mm)
•
Precision knobs•
Illuminated knob•
ComfortSwivel handle •
Motorized lift-up control panel•
Sabbath program•
MultiLingua•
MyMiele•
Time synchronization•
Time of day display•
Date display•
Minute minder•
Automatic switch-off•
Programmable cooking time•
Actual temperature display•
Default temperatures•
Acoustic signal when desired temperature is reached•
FavoritesYes
Individual settings•
Timed bursts of steam•
CleanGlass door•
Door contact switch•
SoftClose oven door/ SoftOpen •
Oven cavity volume in cu. ft. (l)5.76 (163) ft³ (l)
Number of oven shelf levels6
No. of halogen lampsdouble
TwinPower hot air fans•
Energy-saving lighting circuit•
Residual heat utilization•
Rapid PreHeat•
Stainless-steel front with partial Clean Touch Steel finish•
Oven with self-cleaning program•
AirClean catalyzer•
Heated
ComfortClean dishwasher-safe grates•
Cooktop surfaceBlack enamel
Appliance cooling system with cool touch front•
Safety cut-out•
System lock•
Door contact switch•
Door lock during self cleaning•
Appliance width in inches35 15/16
Appliance width in in.(mm)36 1/8 (915)
Appliance height min in in.(mm)37 1/8 (942)
Appliance height max in in.(mm)38 5/8 (980)
Appliance depth in in. (depth) with bullnose27 3/4 (702)
Power Rating in V120
Convertible voltage in V240/208
Fuse rating in A30
Number of phases1
Fresh water connection for Moisture Plus•
Plumbed water connection for Moisture Plus1.50

Optional products and accessories

HBS 70

Miele Gourmet baking and pizza stone

for achieving the same results as if baked in a stone oven.

HEG

Handle

For safe removal of hot, fully-loaded trays and racks.

HBD 60-22

Gourmet casserole dish lid

for Miele HUB 61-22, HUB 62-22, HUB 5000-M, and HUB 5001-M oven dishes.

HBD 60-35

Gourmet casserole dish lid

for Miele HUB 61-35, HUB 5000-XL, and HUB 5001-XL oven dishes.

HBBL 71

Gourmet baking and AirFry tray, perforated

for everything that is crunchy and crisp.

HBF 27-1

Round baking tray

with PerfectClean finish.

HUBB 30-1

Genuine Miele multi-purpose tray

with PerfectClean finish.

HGGB 30-1

Broiling and roasting insert for universal tray

with PerfectClean finish.

HBBR 36-2

Genuine Miele baking and roasting rack

with PyroFit finish.

HFCBBR 36-2

Original Miele FlexiClip with baking and roasting rack

with PyroFit finish.

Downloads, CAD, & apps
  • Product sheet
    PDF
  • Warranty conditions
    PDF
  • Operating and Installation instructions
    PDF
  • Operating and Installation instructions
    PDF

Follow the link and you will find all the resources you need for planning and installing any of our products

  • fbx
    ZIP
  • ifc
    ZIP
  • dwg
    ZIP
  • rvt
    ZIP
  • rfa
    ZIP

Follow the link and you will find all the resources you need for planning and installing any of our products

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorized experts. In the event of queries, please call us for some no-obligation advice!
Descriptions

HR1935G, HR1935-2, HR1935-3 (installation drawing)

E = Electric Connection

W = Water connection

G = Gas connection

Descriptions

HR19x4, HR193x, HR195x (installation drawing)

(x) = Toe-kick height adjustment 5" - 6 1/2" (127 mm - 165.1 mm)

Descriptions

HR11xx, HR19xx, HR 17xx - Installation drawing

1 Anti-tip device

2 Screws

3 Locking nut

Descriptions

HR11xx, HR19xx - Installation drawing

1 Anti-tip device

2 Screws

3 Locking nut

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

1 Anti-tip device

2 Screws

3 Locking nut

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

X 3 13/16" (97 mm): HR1124

HR1134

HR1135

HR1136

HR1724

HR1924

HR1934

HR1935

HR1936

HR1954

HR1955

HR1956

X 3 1/4" (82 mm): HR1134-2

HR1134-3

HR1135-2

HR1135-3

HR1136-2

HR1136-3

HR1924-2

HR1924-3

HR1934-2

HR1934-3

HR1935-2

HR1935-3

HR1936-2

HR1936-3

HR1954-2

HR1954-3

HR1955-2

HR1955-3

HR1956-2

HR1956-3

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

1 Toe kick cover

2 Locking clamp

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

A = Distance between the rear of the range to the supporting wall

Descriptions

HR19xx - Installation drawing

① Maximum depth of top cabinet

② Minimum distance to bottom edge of top cabinet

③ Distance from the floor to cooktop surface

④ Minimum distance to combustible surfaces

E = Electric connection

W = Water connection

G = Gas connection

(A) Width of cabinet opening

(B) Minimum distance between the top of the cooking area and the bottom of an unprotected combustible surface. Minimum distance to a protected combustible surface or when a Miele Ventilation Hood is installed. For all other Hoods please consult the manufacturer's specifications for required distances.

(C) Maximum connection width right and left

(D) Maximum connection height

(E) Maximum connection depth

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

1 Opening in the range housing

2 Bolt of the anti-tip device

3 Locking clamp with slot

Descriptions

HR1924-3, HR1934-3, HR1935-3, HR1936-3, Side view, installation drawing

(x) = Toe-kick height adjustment 5” - 6 1/2” (127 mm - 165.1 mm)

Monitor your Miele appliances while you are on the go.
With the Miele app for your smartphone or tablet you can now connect all your Miele appliances and benefit from its smart home features.
Play Store
App Store
  • 1.Additional digital offer from Miele & Cie. KG. All smart applications are made possible with the Miele@home system. The range of functions can vary depending on the model and the country.
  • Subject to technical changes; no liability accepted for the accuracy of the information given.
To top of page
