HR 1136-3 LP AG GD
$8,799.00
Find a dealer

Product Information

36 inch range All Gas with DirectSelect, Twin convection fans and M Pro dual stacked burners
  • Turn dial operation with display - DirectSelect
  • Maximum variety - four powerful burners and a griddle
  • Fast heating time and even heat distribution – TwinPower
  • Easy clean-up - Self-cleaning and dishwasher-safe grates
  • Easy opening & closing - noise and vibration absorbers

Inside the Box

  • Self Clean ready baking and roasting rack (1)
  • Self clean ready baking and roasting racks with rail system (1)
  • Side racks self clean ready (1)

HR 1136-3 LP AG GD

36 inch range All Gas with DirectSelect, Twin convection fans and M Pro dual stacked burners
  • Subject to technical changes; no liability accepted for the accuracy of the information given.

Product Information

36 inch range All Gas with DirectSelect, Twin convection fans and M Pro dual stacked burners
  • Turn dial operation with display - DirectSelect
  • Maximum variety - four powerful burners and a griddle
  • Fast heating time and even heat distribution – TwinPower
  • Easy clean-up - Self-cleaning and dishwasher-safe grates
  • Easy opening & closing - noise and vibration absorbers

Inside the Box

  • Self Clean ready baking and roasting rack (1)
  • Self clean ready baking and roasting racks with rail system (1)
  • Side racks self clean ready (1)

Your exclusive advantages

Features depend on model – images are only examples and used for explanation purposes

Product data sheet

All gas
Gas typeLiquid gas
Range
Appliance width in inches36
Broil
Intensive
Bake
Convection Roast
Appliance colorClean Touch Steel
Oven displayEasyControl
Number of gas burners4
Number of TrueSimmer burners x power in BTU1 x 8.000
Number of power burners x power in BTU1 x 9.000
Number of high burners x power in BTU2 x 19.500
True Simmer function
GasStop
Number of griddle surfaces1 x 14.300
Width of griddle surface in in.(mm)10 1/4 (258) in (mm)
Depth of griddle surface in in.(mm)17 1/8 (434) in (mm)
Precision knobs
Time of day display
Minute minder
Automatic switch-off
Programmable cooking time
FavoritesNo
Individual settings
CleanGlass door
Door contact switch
SoftClose oven door/ SoftOpen
Oven cavity volume in cu. ft. (l)5.76 (163) ft³ (l)
Number of oven shelf levels6
No. of halogen lamps2
TwinPower hot air fans
Stainless-steel front with partial Clean Touch Steel finish
Oven with self-cleaning program
ComfortClean dishwasher-safe grates
Cooktop surfaceBlack enamel
Appliance cooling system with cool touch front
Safety cut-out
System lock
Door contact switch
Door lock during self cleaning
Appliance width in inches35 15/16
Appliance width in in.(mm)36 1/8 (915)
Appliance height min in in.(mm)37 1/8 (942)
Appliance height max in in.(mm)38 5/8 (980)
Appliance depth in in. (depth) with bullnose27 1/2 (698)
Power Rating in V120
Fuse rating in A15
Number of phases1

Optional products and accessories

Downloads, CAD, & apps
  • Product sheet
    PDF
  • Warranty conditions
    PDF
  • Operating and Installation instructions
    PDF
  • Operating and Installation instructions
    PDF

Follow the link and you will find all the resources you need for planning and installing any of our products

  • dwg
    ZIP
  • rfa
    ZIP
  • rvt
    ZIP
  • fbx
    ZIP
  • ifc
    ZIP

Follow the link and you will find all the resources you need for planning and installing any of our products

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorized experts. In the event of queries, please call us for some no-obligation advice!
Descriptions

HR 11xx (Installation drawing)

(x) = Toe-kick height adjustment 5" - 6 1/2" (127 mm - 165.1 mm)

Descriptions

H1xxx installation drawings

1 29 11/16" / 754 mm

2 23 3/4" / 603

6 mm

3 2 5/8" / 66

5 mm

4 1 11/16" / 43 mm

5 1 11/16" / 42

5 mm

Descriptions

HR 11xx (Installation drawing)

Descriptions

HR1136G (installation drawing)

E = Electric connection

G = Gas connection

Descriptions

HR1136G (installation drawing)

(x) = Toe-kick height adjustment 5" - 6 1/2" (127 mm - 165.1 mm)

Descriptions

HR11xx, HR19xx, HR 17xx - Installation drawing

1 Anti-tip device

2 Screws

3 Locking nut

Descriptions

HR11xx, HR19xx - Installation drawing

1 Anti-tip device

2 Screws

3 Locking nut

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

1 Anti-tip device

2 Screws

3 Locking nut

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

X 3 13/16" (97 mm): HR1124

HR1134

HR1135

HR1136

HR1724

HR1924

HR1934

HR1935

HR1936

HR1954

HR1955

HR1956

X 3 1/4" (82 mm): HR1134-2

HR1134-3

HR1135-2

HR1135-3

HR1136-2

HR1136-3

HR1924-2

HR1924-3

HR1934-2

HR1934-3

HR1935-2

HR1935-3

HR1936-2

HR1936-3

HR1954-2

HR1954-3

HR1955-2

HR1955-3

HR1956-2

HR1956-3

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

1 Toe kick cover

2 Locking clamp

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

A = Distance between the rear of the range to the supporting wall

Descriptions

HR1124, HR1134, HR1135, HR1136HR1124-1, HR1134-1, HR1135-1, HR1136-1, HR1124-3, HR1134-3, HR1135-3, HR1136-3 - Installation drawing

① Maximum depth of top cabinet

② Minimum distance to bottom edge of top cabinet

③ Distance from the floor to cooktop surface

④ Minimum distance to combustible surfaces

E = Electric connection

G = Gas connection

(A) Width of cabinet opening

(B) Minimum distance between the top of the cooking area and the bottom of an unprotected combustible surface.

Minimum distance to a protected combustible surface or when a Miele Ventilation Hood is installed. For all other

Hoods please consult the manufacturer's specifications for required distances.

(C) Maximum connection width right and left

(D) Maximum connection height

(E) Maximum connection depth

Descriptions

HR11xx, HR19xx, HR17xx - Installation drawing

1 Opening in the range housing

2 Bolt of the anti-tip device

3 Locking clamp with slot
