Product Information
Inside the Box
- Self Clean ready baking and roasting rack (1)
- Self clean ready baking and roasting racks with rail system (1)
- Side racks self clean ready (1)
HR 1134-3 LP AG
- Subject to technical changes; no liability accepted for the accuracy of the information given.
Product Information
Inside the Box
- Self Clean ready baking and roasting rack (1)
- Self clean ready baking and roasting racks with rail system (1)
- Side racks self clean ready (1)
Your advantages
Self Clean Oven and Self Clean Ready Accessories
Treat yourself to minimum effort
ComfortClean Dishwasher-Safe Grates
Efficiently protects and makes cleaning easier
Self Clean Oven and Self Clean Ready Accessories
Treat yourself to minimum effort
Clean Touch Steel™Front
Protection for immaculate stainless steel surfaces
Individual settings
Appliance configuration according to your wishes
Timer Function
Leave time management to your oven
Soft Open and Soft Close
Everything is well thought through
TwinPower Convection Blowers and Power Convection Blower
Reaches the desired temperature very quickly
Cooling System and Cool-Touch Fronts
Pleasantly cool surfaces
Safety functions
Automatic switch-off for maximum safety
Convection Roast
Bake
Broil
Convection Bake
Convection Roast
Product data sheet
| All gas | • |
| Gas type | Liquid propane |
| Range | • |
| Appliance width in inches | 36 |
| Broil | • |
| • | |
| • | |
| Bake | • |
| Convection Roast | • |
| Appliance color | Clean Touch Steel |
| Oven display | EasyControl |
| Number of gas burners | 6 |
| Number of TrueSimmer burners x power in BTU | 1 x 8.000 |
| Number of power burners x power in BTU | 2 x 9.000 |
| Number of high burners x power in BTU | 3 x 19.500 |
| True Simmer function | • |
| GasStop | • |
| Precision knobs | • |
| Time of day display | • |
| Minute minder | • |
| Automatic switch-off | • |
| Programmable cooking time | • |
| Favorites | No |
| Individual settings | • |
| CleanGlass door | • |
| Door contact switch | • |
| SoftClose oven door/ SoftOpen | • |
| Oven cavity volume in cu. ft. (l) | 5.76 (163) ft³ (l) |
| Number of oven shelf levels | 6 |
| No. of halogen lamps | double |
| TwinPower hot air fans | • |
| Stainless-steel front with partial Clean Touch Steel finish | • |
| Oven with self-cleaning program | • |
| ComfortClean dishwasher-safe grates | • |
| Cooktop surface | Black enamel |
| Appliance cooling system with cool touch front | • |
| Safety cut-out | • |
| System lock | • |
| Door contact switch | • |
| Door lock during self cleaning | • |
| Appliance width in inches | 35 15/16 |
| Appliance width in in.(mm) | 36 1/8 (915) |
| Appliance height min in in.(mm) | 37 1/8 (942) |
| Appliance height max in in.(mm) | 38 5/8 (980) |
| Appliance depth in in. (depth) with bullnose | 27 3/4 (702) |
| Power Rating in V | 120 |
| Fuse rating in A | 15 |
| Number of phases | 1 |
Optional products and accessories
- Operating and Installation instructionsPDF
- Operating and Installation instructionsPDF
- Warranty conditionsPDF
- Product sheetPDF
Follow the link and you will find all the resources you need for planning and installing any of our products
- fbxZIP
- dwgZIP
- rfaZIP
- rvtZIP
- ifcZIP
Follow the link and you will find all the resources you need for planning and installing any of our products
HR11xx, HR1724 (Installation drawing)
HR1134, HR1134-1, HR1124-3 (installation drawing)
E = Electric connection
G = Gas connection
HR1135G, HR1135-1 (installation drawing)
(x) = Toe-kick height adjustment 5" - 6 1/2" (127 mm - 165.1 mm)
HR11xx, HR19xx, HR 17xx - Installation drawing
1 Anti-tip device
2 Screws
3 Locking nut
HR11xx, HR19xx - Installation drawing
1 Anti-tip device
2 Screws
3 Locking nut
HR11xx, HR19xx, HR17xx - Installation drawing
1 Anti-tip device
2 Screws
3 Locking nut
HR11xx, HR19xx, HR17xx - Installation drawing
X 3 13/16" (97 mm): HR1124
HR1134
HR1135
HR1136
HR1724
HR1924
HR1934
HR1935
HR1936
HR1954
HR1955
HR1956
X 3 1/4" (82 mm): HR1134-2
HR1134-3
HR1135-2
HR1135-3
HR1136-2
HR1136-3
HR1924-2
HR1924-3
HR1934-2
HR1934-3
HR1935-2
HR1935-3
HR1936-2
HR1936-3
HR1954-2
HR1954-3
HR1955-2
HR1955-3
HR1956-2
HR1956-3
HR11xx, HR19xx, HR17xx - Installation drawing
1 Toe kick cover
2 Locking clamp
HR11xx, HR19xx, HR17xx - Installation drawing
A = Distance between the rear of the range to the supporting wall
HR1124, HR1134, HR1135, HR1136HR1124-1, HR1134-1, HR1135-1, HR1136-1, HR1124-3, HR1134-3, HR1135-3, HR1136-3 - Installation drawing
① Maximum depth of top cabinet
② Minimum distance to bottom edge of top cabinet
③ Distance from the floor to cooktop surface
④ Minimum distance to combustible surfaces
E = Electric connection
G = Gas connection
(A) Width of cabinet opening
(B) Minimum distance between the top of the cooking area and the bottom of an unprotected combustible surface.
Minimum distance to a protected combustible surface or when a Miele Ventilation Hood is installed. For all other
Hoods please consult the manufacturer's specifications for required distances.
(C) Maximum connection width right and left
(D) Maximum connection height
(E) Maximum connection depth
HR11xx, HR19xx, HR17xx - Installation drawing
1 Opening in the range housing
2 Bolt of the anti-tip device
3 Locking clamp with slot
HR1124-3, HR1134-3, HR1135-3, HR1136-3, HR1724-3, Side view, installation drawing
(x) = Toe-kick height adjustment 5” - 6 1/2” (127 mm - 165.1 mm)
