KFMC 3632 R Compatible with furniture fronts
MasterFresh Pro | AirClean system | IceMaker | M Touch Pro | ColdSteelProduct details
- Food stays fresh for up to 5 times longer –MasterFresh ProLoading...
- Up to 95% less odors – thanks toLonglife AirClean SystemLoading...
- Ice cubes for cold drinks –IceMakerLoading...
- Convenient operation at your fingertips –M Touch ProLoading...
- Sophisticated interior design – ColdSteel
- View manufacturer details:
- Safety information
Product data sheet
- Model number
- KFMC 3632 R
- Manufacturer material number
- 12489450
- EAN number
- 4002516768685
- Marketing classLoading...
- Platinum
- Fridge-freezer
- Built-in
- Built-in integrated
- Door hinge side
- right
- Convertible hinging
- Can be installed side-by-sideLoading...
- Design option
- Compatible with furniture fronts
- LightingLoading...
- BrilliantLight
- SmartLightLoading...
- Networking with Miele@homeLoading...
- Freshness system
- MasterFresh Pro + DailyFresh ExtraCool
- Longlife AirClean SystemLoading...
- DynaCoolLoading...
- NoFrost
- DuplexCool ProLoading...
- SoftClose door closing damperLoading...
- SelfClose
- Number of IceMakers with plumbed water connection
- 1
- IceMaker with mains water connectionLoading...
- FullAccess
- EasyClean
- MaxLoad hingeLoading...
- Cooling tipsLoading...
- Cooling modesLoading...
- IceMakerLoading...
- Push notificationsLoading...
- RemoteUpdateLoading...
- Smart Home IntegrationLoading...
- Electronic temperature display and control
- M Touch Pro
- Precise adjustment
- Fridge and freezer temperature
- Independent temperature control of fridge and freezer compartments
- SuperCool&AirClean
- SuperFrost
- No. of temperature zones
- 3
- Sabbath mode
- Holiday modeLoading...
- Eco modeLoading...
- QuickIce
- Height-adjustable, full-width tempered glass shelves
- 2
- Number of VeggieBoxes
- 1
- No. of humidity-controlled compartments
- 1
- Door rack for tins
- 2
- Inner door racks for bottles
- 1
- Number of freezer baskets
- 3
- of which on telescopic rails
- 2
- Energy Star Qualified
- Spill-proof glass shelvesLoading...
- Acoustic door alarm
- Acoustic temperature alarm, freezer section
- Niche width in inches (mm), min.
- 30 (762)
- Niche width in inches (mm), max.
- 30 (762)
- Niche height in inches (mm), min.
- 84 1/8 (2134)
- Niche height in inches (mm), max.
- 84 1/8 (2134)
- Niche depth in in.(mm)
- 25 (635)
- Appliance dimensions (W x H x D) in inches (mm)
- 29 3/4 (756) x 83 5/8 (2125) x 23 7/8 (608)
- Appliance width in in.(mm)
- 29 3/4 (756)
- Appliance height in in.(mm)
- 83 5/8 (2125)
- Appliance depth in in.(mm)
- 23 7/8 (608)
- Weight in lbs.(kg)
- 435 (197.0)
- Type of mounting
- Fixed door
- Maximum fridge compartment door front weight in lbs. (kg)
- 133 (60)
- Maximum freezer compartment door front weight in lbs. (kg)
- 38 (17)
- Fridge compartment volume in cu. ft. (l)
- 10.91 (309)
- 4-star freezer compartment volume in cu. ft. (l)
- 5.62 (159)
- Total usable capacity in cu. ft. (l)
- 16.53 (468)
- Current consumption in milliampere (mA)
- 4000
- Voltage in V
- 110 - 120
- Fuse rating in A
- 10
- Number of phases
- 1
- Frequency in Hz
- 60
- Wire length in ft (m)
- 9.8 (3.0)
- Replacing bulbs
- Customer Service
- Longlife AirClean filter
- Water filter
- Ice scoop
- EAN
- 4002516768685
What's included
- Longlife AirClean filter
- Water filter
- Ice scoop
- *This is a separate digital offer from Miele & Cie. KG. The range of functions can vary depending on the model and the country. Acceptance of the Terms and Conditions and Privacy Policy for Miele digital products and services in the Miele app required. Miele reserves the right to change or discontinue the digital offer at any time.
Protective storage for long-lasting freshnessMasterFresh Pro
The drawers of your Miele MasterCool appliance provide the perfect climate for the gentle storage of your food.
Fresh food without unpleasant odorsLonglife AirClean System
The reactivatable filter preserves the freshness of your food and reduces odors by up to 95%*.1,
Ice cubes for cold drinksIceMaker
The IceMaker delivers 3 lb (1.4 kg) of ice cubes a day – with a water connection and filter for good water quality
User convenience

Longlife AirClean System
The reactivatable filter preserves the freshness of your food and reduces odors by up to 95%*.1,
Spill-proof glass shelves
The overflow protection integrated into the glass shelves holds back liquids.
SmartLight
Define how much the interior lighting is dimmed down in the evening – for glare-free illumination.
Gallon bins
There is space for large containers in the door shelves and plenty of room inside for all your food.
DynaCool
A fan ensures a uniform temperature throughout the entire fridge section, so you are entirely free to choose where to store your food.
NoFrost
The sophisticated NoFrost system provides the convenience of no longer having to defrost or clean the appliance.
Miele@home2,
Make your life smart: Thanks to Miele@home, you can cleverly network your domestic appliances – for more options.Convenience features

MasterFresh Pro
The drawers of your Miele MasterCool appliance provide the perfect climate for the gentle storage of your food.
IceMaker
The IceMaker delivers 3 lb (1.4 kg) of ice cubes a day – with a water connection and filter for good water quality
DailyFresh ExtraCool
Food stays fresh for longer in the spacious drawer.User interfaces

M Touch Pro
For maximum convenience, a wide range of settings can be made with a touch of a fingertip.Quality

MaxLoad hinge
The high load size of the door hinges ensures smooth opening of large doors and provides stability.Smart Extras
Get more out of your refrigeration applianceCooling tips2,
Get the most out of your refrigeration appliances thanks to tips and advice in the Miele app.
Always up to date with software updatesRemoteUpdate2,
Bringing new functions directly to your appliance.
Flexible storage for any occasionCooling modes2,
Quickly adapt your cooling settings to any situation with preset options.
Seamless networking throughout your homeSmart Home Integration2,
Intelligent integration of Miele appliances into a Smart Home system.
Smart alerts keep you informedPush notifications2,
Maintain optimal cooling and ideal conditions with push notifications alerting you to changes.
Ice cubes when you need themIceMaker2,
Get fresh ice when you want it by turning the ice maker on and off in the Miele app.
Matching products and accessories
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts.










- 1.Comparison of a MasterCool KFMC 3XXX model with and without Longlife AirClean System after 24 hours. Applied method according to DIN EN 13735. Tested refrigerator load: smoked fish, mature cheese, spring onions, pineapple.
- 2.This is a separate digital offer from Miele & Cie. KG. The range of functions can vary depending on the model and the country. Acceptance of the Terms and Conditions and Privacy Policy for Miele digital products and services in the Miele app required. Miele reserves the right to change or discontinue the digital offer at any time.
We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
