MasterCool™ fridge-freezerDIAMOND

KFMC 3836 L Compatible with furniture fronts

Color:Compatible with furniture fronts
sale price$13,499.00


Product details

  • Food stays fresh for up to 5 times longer –
    MasterFresh Pro
  • Up to 95% less odors – thanks to
    Longlife AirClean System
  • Ice cubes for cold drinks –
    IceMaker
  • Chilled water at any time –
    Water dispenser
  • View manufacturer details:
  • Safety information

Product data sheet

Fridge-freezer
Built-in
Built-in integrated
Door hinge side Left
Convertible hinging
Can be installed side-by-side
Design option Compatible with furniture fronts
Lighting
BrilliantLight Pro
SmartLight
Networking with Miele@home
Freshness system MasterFresh Pro + DailyFresh ExtraCool
Longlife AirClean System
DynaCool
NoFrost
DuplexCool Pro
SoftClose door closing damper
SelfClose
Number of IceMakers with plumbed water connection 1
IceMaker with mains water connection
FullAccess
EasyClean
MaxLoad hinge
Electronic temperature display and control M Touch Pro
Precise adjustment Fridge and freezer temperature
Fridge compartment can be switched off No
Independent temperature control of fridge and freezer compartments
SuperCool&AirClean
SuperFrost
No. of temperature zones 3
Sabbath mode
Holiday mode
Eco mode
Eco mode
QuickIce
Height-adjustable, full-width tempered glass shelves 2
Number of VeggieBoxes 1
No. of humidity-controlled compartments 1
Door rack for tins 2
Inner door racks for bottles 1
Water dispenser
Number of freezer baskets 3
of which on telescopic rails 2
Energy Star Qualified
Spill-proof glass shelves
Acoustic door alarm
Acoustic temperature alarm, freezer section
Niche width in inches (mm), min. 30 (762)
Niche width in inches (mm), max. 30 (762)
Niche height in inches (mm), min. 84 1/8 (2134)
Niche height in inches (mm), max. 84 1/8 (2134)
Niche depth in in.(mm) 25 (635)
Appliance dimensions (W x H x D) in inches (mm) 29 3/4 (756) x 83 5/8 (2125) x 23 7/8 (608)
Appliance width in in.(mm) 29 3/4 (756)
Appliance height in in.(mm) 83 5/8 (2125)
Appliance depth in in.(mm) 23 7/8 (608)
Weight in lbs.(kg) 441 (200.0)
Type of mounting Fixed door
Maximum fridge compartment door front weight in lbs. (kg) 133 (60)
Maximum freezer compartment door front weight in lbs. (kg) 38 (17)
Fridge compartment volume in cu. ft. (l) 10.91 (309)
4-star freezer compartment volume in cu. ft. (l) 5.62 (159)
Total usable capacity in cu. ft. (l) 16.53 (468)
Current consumption in milliampere (mA) 4000
Voltage in V 110-120
Fuse rating in A 10
Number of phases 1
Frequency in Hz 60
Wire length in ft (m) 9 (3.0)
Replacing bulbs Customer Service
Longlife AirClean filter
Water filter
Ice scoop
EAN 4002516768586

What's included

Longlife AirClean filter
Ice scoop
Water filter
  • Protective storage for long-lasting freshness

    Protective storage for long-lasting freshness

    MasterFresh Pro

    The drawers of your Miele MasterCool appliance provide the perfect climate for the gentle storage of your food.

  • Everything in full view at all times – cameras in the refrigerator

    Everything in full view at all times – cameras in the refrigerator

    Cameras in the refrigerator2,

    View images of your supplies in the fridge zone using the Miele app at any time and from anywhere.

  • Fresh food without unpleasant odors

    Fresh food without unpleasant odors

    Longlife AirClean System

    The reactivatable filter preserves the freshness of your food and reduces odors by up to 95%*.

  • Ice cubes for cold drinks

    Ice cubes for cold drinks

    IceMaker

    The IceMaker delivers 3 lb (1.4 kg) of ice cubes a day – with a water connection and filter for good water quality

  • Chilled water at any time

    Chilled water at any time

    Water dispenser

    Integrated water dispenser for chilled and filtered water at any time.

User convenience

Everything in full view at all times – cameras in the refrigerator
Everything in full view at all times – cameras in the refrigerator

Cameras in the refrigerator2,

View images of your supplies in the fridge zone using the Miele app at any time and from anywhere.1,
Fresh food without unpleasant odors
Fresh food without unpleasant odors

Longlife AirClean System

The reactivatable filter preserves the freshness of your food and reduces odors by up to 95%*.3,
Practical illumination with elegant LEDs
Practical illumination with elegant LEDs

BrilliantLight Pro

Soft and attractive high-quality LED light strips offer perfect illumination and a beautiful lighting mood.
Protection when liquids leak
Protection when liquids leak

Spill-proof glass shelves

The overflow protection integrated into the glass shelves holds back liquids.
Individually customizable lighting
Individually customizable lighting

SmartLight

Define how much the interior lighting is dimmed down in the evening – for glare-free illumination.
Perfect food storage
Perfect food storage

DynaCool

A fan ensures a uniform temperature throughout the entire fridge section, so you are entirely free to choose where to store your food.
Defrosting is a thing of the past
Defrosting is a thing of the past

NoFrost

The sophisticated NoFrost system provides the convenience of no longer having to defrost or clean the appliance.
Cleverly networked
Cleverly networked

Miele@home2,

Make your life smart: Thanks to Miele@home, you can cleverly network your domestic appliances – for more options.

Convenience features

Protective storage for long-lasting freshness
Protective storage for long-lasting freshness

MasterFresh Pro

The drawers of your Miele MasterCool appliance provide the perfect climate for the gentle storage of your food.
Ice cubes for cold drinks
Ice cubes for cold drinks

IceMaker

The IceMaker delivers 3 lb (1.4 kg) of ice cubes a day – with a water connection and filter for good water quality
Chilled water at any time
Chilled water at any time

Water dispenser

Integrated water dispenser for chilled and filtered water at any time.
More freshness thanks to low-temperature drawer
More freshness thanks to low-temperature drawer

DailyFresh ExtraCool

Food stays fresh for longer in the spacious drawer.

User interfaces

Convenient operation at your fingertips
Convenient operation at your fingertips

M Touch Pro

For maximum convenience, a wide range of settings can be made with a touch of a fingertip.

Quality

Safe handling guaranteed
Safe handling guaranteed

MaxLoad hinge

The high load size of the door hinges ensures smooth opening of large doors and provides stability.

Matching products and accessories

IntensiveClear 2.0
KWF 2000

IntensiveClear 2.0

Water filter with active charcoal for MasterCool F 2xx2, KF 2xx2, KFMC 3xxx.

$189.00
Decor set
DS7308 Handle EDST/CLST

Decor set

for retrofitting built-in series handle on kitchen cabinetry.

$185.90
Decor set
DS 7808 PureLine EDST/CLST

Decor set

for retrofitting built-in series handle on kitchen cabinetry.

$185.90
IntensiveClear 2.0
KB 2000

IntensiveClear 2.0

Strainer filter for MasterCool F 2xx2 and KF 2xx2.

$163.80
Decor set

Decor set

for retrofitting built-in series handle on kitchen cabinetry.

$163.90
Stainless steel front

Stainless steel front

for attractive integration of KFMC 3xxx bottom-mount units.

$899.00
Stainless steel front

Stainless steel front

for attractive integration of KFMC 3xxx bottom-mount units.

$449.00
Side-by-side kit

Side-by-side kit

for high-quality side-by-side installation of KFMC 3xxx models.

$649.00
MicroCloth kit, 3 pieces
GP MI S 0031 W

MicroCloth kit, 3 pieces

For best cleaning results and safe use.

$17.59
 MicroCloth HyClean, 1 cloth
GP MI H 0011 W

 MicroCloth HyClean, 1 cloth

 Antibacterial multi-purpose cloth for improved hygiene.

$13.19

Downloads

Fitting Instructions
PDF
Downloads
Product sheet
PDF
Downloads
Operating instructions/Installation instructions
PDF
Downloads
Warranty conditions
PDF
Downloads
dwg
ZIP
Downloads
fbx
ZIP
Downloads
ifc
ZIP
Downloads
rfa
ZIP
Downloads
rvt
ZIP
Downloads
Energy label
PDF
Downloads
PNG
Downloads
Energy label
JPEG
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts.

https://media.miele.com/images/2000021/200002193/20000219394.png
Descriptions
KFMC3632R+L, KFMC3836R+L, MasterCool III, stainless steel frame, stainless steel front, installation
View from the front, 1. Mains connection cable, L = 3000 mm (118 inch), 2. Water connection L = 1800 mm (70 inch)
POSTSCRIPT
Downloads
https://media.miele.com/images/2000021/200002194/20000219401.png
Descriptions
KFMC3632R+L, KFMC3836R+L, KFMC3834R+L, MasterCool III, installation, panel ready
Information for KFMC 3632 L + R, KFMC 3836 L + R (US/CD) only, View from the front, 1. Mains connection cable, L = 3000 mm (118 inch), 2. Water connection L = 1800 mm (70 inch), Information for KFMC 3834 L + R (EU) , 1. Mains connection cable, L = 3000 mm , 2. Water connection L = 18mm mm
POSTSCRIPT
Downloads
https://media.miele.com/images/2000021/200002194/20000219407.png
Descriptions
KFMC3632R+L, KFMC3836R+L, MasterCool III, stainless steel frame, with stainless steel front, integration
KFMC3632R+L, KFMC3836R+L, MasterCool III, stainless steel frame, with stainless steel front, integration
POSTSCRIPT
Downloads
https://media.miele.com/images/2000021/200002194/20000219411.png
Descriptions
KFMC3632R+L, KFMC3836R+L, KFMC3834R+L, MasterCool III, integration, panel ready
KFMC3632R+L, KFMC3836R+L, KFMC3834R+L, MasterCool III, integration, panel ready
POSTSCRIPT
Downloads
https://media.miele.com/images/2000021/200002194/20000219424.png
Descriptions
KFMC3632R+L, KFMC3836R+L, KFMC3834R+L, MasterCool III, front view, installation
1. 60 kg / 132,2 lbs, 2. 17 kg / 37,5 lbs
POSTSCRIPT
Downloads
https://media.miele.com/images/2000021/200002195/20000219504.png
Descriptions
KFMC3632R+L, KFMC3642R+L, KFMC3836R+L, KFMC3858FD, MasterCool III, frame neutral, installation
KFMC3632R+L, KFMC3642R+L, KFMC3836R+L, KFMC3858FD, MasterCool III, frame neutral, installation
POSTSCRIPT
Downloads
https://media.miele.com/images/2000021/200002195/20000219505.png
Descriptions
KFMC3632R+L, KFMC3642R+L, KFMC3836R+L, KFMC3834R+L, KFMC3858FD, MasterCool III, hinge clearance, installation
KFMC3632R+L, KFMC3642R+L, KFMC3836R+L, KFMC3834R+L, KFMC3858FD, MasterCool III, hinge clearance, installation
POSTSCRIPT
Downloads
https://media.miele.com/images/2000021/200002195/20000219506.png
Descriptions
KFMC3632R+L, KFMC3642R+L, KFMC3836R+L, KFMC3834R+L, KFMC3858FD, MasterCool III, Side-view bottom, installation
KFMC3632R+L, KFMC3642R+L, KFMC3836R+L, KFMC3834R+L, KFMC3858FD, MasterCool III, Side-view bottom, installation
POSTSCRIPT
Downloads
https://media.miele.com/images/2000021/200002195/20000219517.png
Descriptions
KFMC3632R+L, KFMC3836R+L, MasterCool III, stainless steel frame, with stainless steel front, top view
KFMC3632R+L, KFMC3836R+L, MasterCool III, stainless steel frame, with stainless steel front, top view
POSTSCRIPT
Downloads
https://media.miele.com/images/2000021/200002195/20000219518.png
Descriptions
KFMC3632R+L, KFMC3836R+L, KFMC3834R+L, MasterCool III, panel ready, top view
KFMC3632R+L, KFMC3836R+L, KFMC3834R+L, MasterCool III, panel ready, top view
POSTSCRIPT
Downloads
  • 1.The latest version of the Miele app is required in order to use the networking function and the additional digital offers. This is planned to be available from April 2026.
  • 2.This is a separate digital offer from Miele & Cie. KG. The range of functions can vary depending on the model and the country. Acceptance of the Terms and Conditions and Privacy Policy for Miele digital products and services in the Miele app required. Miele reserves the right to change or discontinue the digital offer at any time.
  • 3.Comparison of a MasterCool KFMC 3XXX model with and without Longlife AirClean System after 24 hours. Applied method according to DIN EN 13735. Tested refrigerator load: smoked fish, mature cheese, spring onions, pineapple.
