Induction Cooktop
KM 6320
with PowerFlex cooking area for maximum versatility and performance.Permanently out of stock
Product data sheet
- Model number
- KM 6320
- Manufacturer material number
- 09775880
- EAN number
- 4002515472903
- Marketing classLoading...
- Gold
- Fuel type
- Induction
- Independent of oven
- Elegant glass ceramic surface
- Ceramic surface color
- Black
- All-round stainless-steel frame
- Print design
- LightPrint
- Proud installation
- No. of rings
- 3
- No.
- 2
- Size in mm
- Ø 150 – 230
- Max. rating in W
- 2200
- Max. booster rating in W
- 3100
- Max. TwinBooster rating in W
- 3850
- Position
- left center
- Type
- Variable cooking zone
- Size in mm
- Ø 180-280
- Max. rating in W
- 2500
- Max. booster rating in W
- 3100
- Position
- right
- Type
- PowerFlex bridge
- Size in mm
- 230x390
- Max. rating in W
- 3550
- Max. booster rating in W
- 5000
- Max. TwinBooster rating in W
- 7700
- Operation via touchpad sensors
- Simple direct selection
- Display color
- Red
- Pan/Pan-size sensors
- Loading...
- Stop & Go function
- Loading...
- Minute minder
- Loading...
- Automatic switch-off for all rings
- Loading...
- AutoBoost
- Loading...
- Keep-warm function
- Loading...
- Individual setting options (e.g. acoustic signal tones)
- Loading...
- Easy to clean ceramic glass
- Loading...
- Safety cut-out
- Loading...
- Lock function
- Loading...
- System lock
- Loading...
- Integrated cooling blower
- Loading...
- Overheating protection
- Loading...
- Dimensions (H x W x D) in mm
- 5 1/8 (128) x 24 3/4 (626) x 21 1/2 (544)
- Width in in. (mm)
- 24 3/4 (626)
- Height in in. (mm)
- 5 1/8 (128)
- Depth in in. (mm)
- 21 1/2 (544)
- Cut-out dimensions (W x D) with surface-mounted installation in inches (mm)
- 22 3/8 in (567 mm) x 20 1/2 in (518 mm)
- Built-in height with mains connection box in in. (mm)
- 4 7/8 (121)
- Cutout dimensions width in in. (mm) with proud-mounted installation
- 22 3/8 in (567 mm)
- Cutout dimensions depth in in. (mm) with proud-mounted installation
- 20 1/2 in (518 mm)
- Weight in lbs. (kg)
- 39 (18)
- Total connected load in kW
- 7.700
- Voltage in V
- 240
- Frequency in Hz
- 60
- Power cord length in ft. (m)
- 3 (1.2)
- Plug type
- Sup. lead w/ wire-end ferrules
- Connection wire
- EAN
- 4002515472903
What's included
- Connection wire
So that you can devote your time to other thingsKeeping warm
Food ready to serve: The keep warm function controls the temperature in the pan base and prevents food burning.
Maintenance

EasyClean ceramic glass
Food can no longer burn: Because the cooktop surface remains relatively cool, soiling can be removed easily.User convenience

Stop & Go
So nothing will burn: With this function, all cooking zones can be reduced to power level one simultaneously.
Timer
It makes sense: This feature allows you to set a Minute minder.
Auto heat-up
Always at the right time: This function reduces the initial power boost to prevent burning.
Individual settings
Completely unique: basic cooktop settings can be adapted to suit personal preferences.Safety
Safety turn off
Clever: If a cooking zone operates at the same power level for an unusually long time, switch-off is automatic.
Safety and system lock
Extremely useful: both functions prevent accidental or unauthorized switching on of the Cooktop.Overheating protection and fault monitoring
Protects the Cooktop: The cooktop automatically switches off in the case of extreme heat.Setup/function

Efficient and safe
A clear benefit: "no heat loss with induction, and the ceramic glass surface stays relatively cool."Pan size recognition
Convincing: the size of the pan is recognized by the cooktop and energy supplied to this area only.
Keeping warm
Food ready to serve: The keep warm function controls the temperature in the pan base and prevents food burning.Matching products and accessories
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts.

Descriptions
KM 6320 (Installation drawing)
1) Front, 2) Casing depth, 3) Flexible metal Extension hose L = 47 1/4" (1200 mm), 4) Data plate POSTSCRIPT
