  • Miele - KM 3010 G Stainless steel – Cooktops - 1
  • Miele - KM 3010 G Stainless steel – Cooktops - 2
  • Miele - KM 3010 G Stainless steel – Cooktops - 3
  • Miele - KM 3010 G Stainless steel – Cooktops - 4
Gas cooktopSilver

KM 3010 G Stainless steel

with 4 burners
Color:Stainless steel
sale price$2,099.00


Product details

  • Simple controls -single-handed operation via rotary dial control
  • Elegant design – 24 3/4 (626) in (mm) wide gas cooktop on glass for surface-mounted installation
  • Versatile - 4 burners
  • Extremely safe -
    GasStop function
  • Easy cleaning - ComfortClean dishwasher-safe grates
  • View manufacturer details:
  • Safety information

Product data sheet

Model number
KM 3010 G
Manufacturer material number
09272050
EAN number
4002515135051
Marketing class
Silver
Fuel type
Gas
Independent of oven
Ceramic surface color
Black
Cast iron pot rest (matte black enameled)
Miele logo embossed in stainless steel
No. of rings
4
Small burner in kW
1.10
Small burner in BTU/h
3750
Normal burner in kW
1.70
Normal burner in BTU/h
5800
Large burner in kW
2.73
Large burner in BTU/h
9300
Position
front left
Type
High-speed burner
Position
rear left
Type
Economy burner
Position
rear right
Type
Standard burner
Position
front right
Type
Standard burner
Operation via knobs
Electronic ignition with one-handed operation
Dishwasher-save trivets
GasStop
GasStop & ReStart
Dimensions (H x W x D) in mm
2 1/4 (54) x 24 3/4 (626) x 20 3/4 (526)
Dimensions (W x D) in mm
24 3/4 (626) x 2 1/4 (54) x 20 3/4 (526)
Width in in. (mm)
24 3/4 (626)
Height in in. (mm)
2 1/4 (54)
Depth in in. (mm)
20 3/4 (526)
Cut-out dimensions (W x D) with surface-mounted installation in inches (mm)
23 5/8 in (600 mm) x 19 3/4 in (500 mm)
Built-in height with mains connection box in in. (mm)
2 1/2 (63)
Cutout dimensions width in in. (mm) with proud-mounted installation
23 5/8 in (600 mm)
Cutout dimensions depth in in. (mm) with proud-mounted installation
19 3/4 in (500 mm)
Weight in lbs. (kg)
37 (17)
Total connected load in kW
7.200
Position of gas connection
Hinten links
Voltage in V
120
Frequency in Hz
60
Power cord length in ft. (m)
3 (1.2)
Plug type
NEMA plug: 5–15
EAN
4002515135051
  • Efficiently protects and makes cleaning easier
    Efficiently protects and makes cleaning easier

    ComfortClean Dishwasher-Safe Grates

    Fast cleaning: Remove the pot rests and wash in the dishwasher. Fast clean-up with dishwasher-safe grates.

  • Automatic reignition for extra safety
    Automatic reignition for extra safety

    GasStop and ReStart

    Safe cooking: Automatic re-ignition for flame failure If unsuccessful, the gas supply is switched off immediately.

  • The innovative
    The innovative

    Gas cooktops with electronic controls

    More safety and convenience: Intelligent features make cooking with gas a great choice.

Maintenance

Efficiently protects and makes cleaning easier
Efficiently protects and makes cleaning easier

ComfortClean Dishwasher-Safe Grates

Fast cleaning: Remove the pot rests and wash in the dishwasher. Fast clean-up with dishwasher-safe grates.
Best quality features for a long service life
Best quality features for a long service life

Enamelled grates and grates and burner cap

Nothing lasts longer and is easier to clean: enamelled cast-iron grates and burners with PerfectClean.

Design

A gas cooktop for every kitchen style
A gas cooktop for every kitchen style

Individual design

Attractive design to suit all tastes: a minimalist stainless-steel look or elegant ceramic glass.

User convenience

Comfortably reignite the flame
Comfortably reignite the flame

Single-handed electronic ignition

No need for matches or lighters: automatic ignition of burners thanks to intelligent technology.
Everything under control
Everything under control

Comfort handle with integrated controls with knobs

Easy controls to regulate: Convenient power level control via plastic or metal knobs.

Safety

Automatic reignition for extra safety
Automatic reignition for extra safety

GasStop and ReStart

Safe cooking: Automatic re-ignition for flame failure If unsuccessful, the gas supply is switched off immediately.
Flame failure monitor for maximum safety
Flame failure monitor for maximum safety

GasStop

Reassuring: If the flame is extinguished, for example by a draught, the continued supply of gas is prevented.

Features

The innovative
The innovative

Gas cooktops with electronic controls

More safety and convenience: Intelligent features make cooking with gas a great choice.

Downloads

Operating and Installation instructions
PDF
Download
Product sheet
PDF
Download
Warranty conditions
PDF
Download
dwg
ZIP
Download
fbx
ZIP
Download
ifc
ZIP
Download
rfa
ZIP
Download
rvt
ZIP
Download

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts.

https://media.miele.com/dam/bcf6ff4b-1311-419e-8cbe-b3c600a99c26/20000085154_HighresDigitalRGB.png
Descriptions
KM 3010 G (Installation drawing)
1. Front, 2. Casing depth, 3. Mains connection box with mains connection cable L = 2000 mmm, 4. Gas connection R 1/2" - ISO 7-1 (DIN EN 10226)
