Gas cooktop

KM 2032 G Stainless steel

with 5 burners for particularly versatile cooking convenience.

Color:Stainless steel

sale price$1,599.00




Product details

  • Simple controls -single-handed operation via rotary dial control
  • Professional design - 29 5/8 (750) in (mm) wide stainless steel trough
  • Particularly versatile - 5 burners incl. 1 mono wok
  • Extremely safe -
    GasStop function
  • Easy cleaning - ComfortClean dishwasher-safe grates
  • Manufactured with great care by
  • Safety information

Product data sheet

Fuel type Gas
Independent of oven
Proud/flush-mounted –/–
Stainless steel trough
Cast iron pot rest (matte black enameled)
No. of rings 5
Number of cooking zones/cooking areas –/–
Small burner in kW 1.11
Small burner in BTU/h 3800
Normal burner in kW 1.61
Normal burner in BTU/h 5500
Large burner in kW 2.52
Mono wok burner in kW 3.31
Mono wok burner in BTU/h 11300
Position front left
Type High-speed burner
Position rear left
Type Economy burner
Position Centered
Type Single wok burner
Position rear right
Type Standard burner
Position front right
Type Standard burner
Operation via knobs
Electronic ignition with one-handed operation
Dishwasher-save trivets
PerfectClean burner
GasStop
Dimensions (H x W x D) in mm 3 5/8 (90) x 29 5/8 (750) x 20 1/2 (520)
Dimensions (W x D) in mm 29 5/8 (750) x 3 5/8 (90) x 20 1/2 (520)
Width in in. (mm) 29 5/8 (750)
Height in in. (mm) 3 5/8 (90)
Depth in in. (mm) 20 1/2 (520)
Cut-out dimensions (W x D) with surface-mounted installation in inches (mm) 22 1/8 in (560 mm) x 19 in (480 mm)
Cutout dimensions width in in. (mm) with proud-mounted installation 22 1/8 in (560 mm)
Cutout dimensions depth in in. (mm) with proud-mounted installation 19 in (480 mm)
Weight in lbs. (kg) 35 (16)
Total connected load in kW 10.170
Position of gas connection Hinten links
Voltage in V 120
Frequency in Hz 60
Power cord length in ft. (m) 3 (1.2)
Connection wire
EAN 4002515962473

What's included

Connection wire

Maintenance

Best quality features for a long service life
Enamelled grates and grates and burner cap

Nothing lasts longer and is easier to clean: enamelled cast-iron grates and burners with PerfectClean.


Efficiently protects and makes cleaning easier
ComfortClean Dishwasher-Safe Grates

Fast cleaning: Remove the pot rests and wash in the dishwasher. Fast clean-up with dishwasher-safe grates.


Design

A gas cooktop for every kitchen style
Individual design

Attractive design to suit all tastes: a minimalist stainless-steel look or elegant ceramic glass.


User convenience

Comfortably reignite the flame
Single-handed electronic ignition

No need for matches or lighters: automatic ignition of burners thanks to intelligent technology.


Everything under control
Comfort handle with integrated controls with knobs

Easy controls to regulate: Convenient power level control via plastic or metal knobs.


Efficiency and sustainability

Efficient and environmentally friendly
Gas - efficient and environmentally friendly

With environmental and economic benefits: Cooking with gas


Safety

Flame failure monitor for maximum safety
GasStop

Reassuring: If the flame is extinguished, for example by a draught, the continued supply of gas is prevented.


Features

Large variety of burner sizes for every application
Versatile burner configuration

From economical to powerful: There is a suitable burner with the optimum output for every application.


Downloads

Warranty conditions
PDF
Downloads
Product sheet
PDF
Downloads
Operating and Installation instructions
PDF
Downloads
dwg
ZIP
Downloads
rfa
ZIP
Downloads
ifc
ZIP
Downloads
rvt
ZIP
Downloads
fbx
ZIP
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts.

https://media.miele.com/images/2000015/200001552/20000155243.png
Descriptions
KM2032G (installation drawing) USA
1. Front, 2 Building-in depth, 3. Gas connection R 1/2 - ISO 7-1 (DIN 2999), 4. Mains connection box with mains connection cable, L = 1200 mm
