Cooker hoods - DA 1260 Stainless steel - 1
Cooker hoods - DA 1260 Stainless steel - 1
Built-under hood

DA 1260 Stainless steel

with energy-efficient LED lighting and sliding switch for simple operation.
Color:Stainless steel
sale price$999.00




Product details

  • Puristic design – space-saving solution 23 5/8 (598) in (mm) wide
  • Powerful – 320.19 (544) ft³/min (m3/h) in Booster level
  • Efficient filtration-
    10-ply stainless steel grease filters
  • Safe and easy to clean -
    Miele CleanCover
  • Suitable for every home - vented or recirculating
  • Manufactured with great care by
  • Safety information

Product data sheet

Built-under ventilation hood
Recirculated mode Can be retrofitted
OdorFree charcoal filter (order separately) DKF 18-P
Color Stainless steel
Recessed knob controls
Slide switch
Operation Slide switch
Power levels (number excl. Intensive) 3
Booster levels 1
CleanCover
Easy-to-clean canopy interior – CleanCover
Number of dishwasher-safe stainless steel grease filters (10-ply) 2
Number x W 2 x 3 W
Light intensity in Lx 275 lx
Color temperature in K 3000 Kelvin
Single-action blower
Air throughput in CFM in Booster 220
Air throughput Values upon request
Air throughput with Booster level 1 (m³/h) according to EN 61591 320.19 (544)
Canopy width in in. (mm) 23 5/8 (598)
Canopy height in in. (mm) 5 (125)
Depth of hood canopy in in. (mm) 19 3/4 (500)
Minimum height above electric cooktops in mm 17 3/4 (450)
Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm 25 5/8 (650)
Net weight in lbs. (kg) 25 (11.2)
Length of electrical wire in ft. (m) 4 (1.5)
Standard plug fitted
Total connected load in kW 0.286
Voltage in V 120
Fuse rating in A 15
Frequency in Hz 60
Number of phases 1
Vent connection at top
Diameter of vent connection in in. (mm) 6 (150)
Installation template
Non-return flap
Recirculation deflector
EAN 4002515882979

What's included

Non-return flap
Recirculation deflector
Easy to use and effective against grease
Stainless-steel grease filters (10-layer)

Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.

Convenience and safety in detail
Miele CleanCover

Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.

Features

Easy to use and effective against grease
Stainless-steel grease filters (10-layer)

Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.

Convenience and safety in detail
Miele CleanCover

Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.

Matching products and accessories

Reducing collar

For reducing the exhaust air vent cross-section.

$137.50
OdorFree Charcoal Filter

OdorFree Charcoal Filter

for Miele DA 12xx Ventilation Hoods.

$121.00
Reducing collar

Reducing collar

For reducing the exhaust air vent cross-section.

$45.90
Silencer connection

Silencer connection

between silencer and connector.

$38.50

Downloads

Warranty conditions
PDF
Downloads
Product sheet
PDF
Downloads
Operating and Installation instructions
PDF
Downloads
dwg
ZIP
Downloads
rfa
ZIP
Downloads
ifc
ZIP
Downloads
rvt
ZIP
Downloads
fbx
ZIP
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts.

https://media.miele.com/images/2000008/200000804/20000080454.png
Descriptions
DA 1060, DA 1160, DA 1260 (Installation drawing)
Installation drawings
Downloads
https://media.miele.com/images/2000013/200001346/20000134620.png
Descriptions
DA 1060, DA 1160, DA 1260 (Installation drawing)
Installation drawings
Downloads

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
