Product Information
F 2472 Vi
- Subject to technical changes; no liability accepted for the accuracy of the information given.
Product Information
Your exclusive advantages
MasterCool™ - Ice/water dispenser
Ice and chilled water at the touch of a button
MasterCool – NoFrost
Defrosting is a thing of the past
MasterCool – BrilliantLight
Perfectly lit
MasterCool – Push2open
The perfect solution for a handleless design
MasterCool – NoFrost
Defrosting is a thing of the past
MasterCool – MasterSensor
Convenient operation with a tap of a finger
MasterCool – BrilliantLight
Perfectly lit
MasterCool – Push2open
The perfect solution for a handleless design
MasterCool™ - Ice/water dispenser
Ice and chilled water at the touch of a button
MasterCool – MaxLoad hinge
Safe handling guaranteed
Product data sheet
| Freezer | • |
| Built-in | • |
| Built-in integrated | • |
| Door hinge side | Left |
| Can be installed side-by-side | • |
| Lighting | BrilliantLight |
| Networking with Miele@home | • |
| Ice/water dispenser | • |
| Freshness system | Ice-/WaterDispenser BrilliantLight Full Access MaxLoad Schanier NoFrost EasyClean |
| NoFrost | • |
| NoFrost | • |
| SoftClose door closing damper | • |
| Push2open | • |
| FullAccess | • |
| EasyClean | • |
| MaxLoad hinge | • |
| Electronic temperature display and control | MasterSensor |
| SuperFrost | • |
| No. of temperature zones | 1 |
| Sabbath mode | • |
| Eco mode | • |
| Door baskets – small | 1 |
| Door baskets – large | 3 |
| Number of shelves | 2 |
| Number of freezer baskets | 2 |
| Energy Star Qualified | • |
| Lock function | • |
| Acoustic door alarm | • |
| Acoustic temperature alarm, freezer section | • |
| Optical door alarm | • |
| Optical temperature alarm | • |
| Niche width in inches (mm), min. | 18 (457) |
| Niche width in inches (mm), max. | 18 (457) |
| Niche height in inches (mm), min. | 84 1/8 (2134) |
| Niche height in inches (mm), max. | 84 1/8 (2134) |
| Niche depth in in.(mm) | 24 7/8 (629) |
| Appliance width in in.(mm) | 17 7/8 (451) |
| Appliance height in in.(mm) | 83 3/4 (2125) |
| Appliance depth in in.(mm) | 24 (608) |
| Weight in lbs.(kg) | 283 (128.3) |
| Type of mounting | Fixed door |
| Maximum fridge compartment door front weight in lbs. (kg) | 157 (71) |
| Current consumption in milliampere (mA) | 4000 |
| Voltage in V | 110-120 |
| Fuse rating in A | 10 |
| Number of phases | 1 |
| Frequency in Hz | 60 |
| Wire length in ft (m) | 11 (3.5) |
| Replacing bulbs | Customer Service |
| Available display languages via MultiLingua | français eesti ελληνιкά čeština 繁體中文 slovenčina latviesu slovenščina 中文 polski français (FR) lietuviu magyar nederlands hrvatski yкраїнська bahasa malaysia italiano deutsch english (GB) türkçe 日本語 dansk suomi română english (AU) english (CA) español srpski english العربية svenska norsk français (CA) pусский português english (US) 한국어 |
Optional products and accessories
- Operating and Installation instructionsPDF
- Product sheetPDF
- Warranty conditionsPDF
Follow the link and you will find all the resources you need for planning and installing any of our products
- rvtZIP
- ifcZIP
- rfaZIP
- fbxZIP
- dwgZIP
Follow the link and you will find all the resources you need for planning and installing any of our products
- Energy labelPDF
- PNG
- JPEG
Follow the link and you will find all the resources you need for planning and installing any of our products
- Open Source LicencePDF
Follow the link and you will find all the resources you need for planning and installing any of our products
F2462Vi, F2472Vi, F2461Vi, F2471Vi, MasterCool, installation, installation drawings (US, CA)
Side-by-side, MasterCool, without partition wall, with heating mat (Sketch) (with footnote)
1) Heating mat KSK 2001 (EU
AUS
CN) or KSK 2002 (US
CA
MX
BR)
F2413Vi, F2471Vi, F2471SF, F2461Vi, F2411Vi, F2411SF, installation, MasterCool, installation drawings
1. View from the front
2. Mains Connection cable
L = 3000 mm (118 inch)
3. Water inlet positon
L = 2000 mm (not for KON USA)
4. No water/ELT conections permitted in this area
Sideview, MasterCool, Sketch
Side-by-Side, MasterCool, footnote, installation drawings
1. KSK 2001/2002
2. Device A
3. Device B
A = niche device A
B = niche device B
KFP1845ed/cs, KFP1844ed/cs, MasterCool, Front panel, Front dimensions, sketch (US, CA)
Opening angle 90°/115°, right side stop, MasterCool (Sketch) with footnote
A) Appliance door
F 2411 Vi
F 2411 SF
F 2471 Vi
F 2471 SF: 525 mm (20 2/3 inch);
F 2412 Vi
F 2412 SF
F 2413Vi
F 2472 Vi
F 2472 SF: 525 mm (20 2/3 inch);
F 2671 Vi
F 2671 SF: 677 mm (26 2/3 inch);
F 2672 Vi
F 2672 SF: 677 mm (26 2/3 inch);
F 2811 SF
F 2811 Vi: 829 mm (32 2/3 inch);
F 2812 SF
F 2812 Vi: 829 mm (32 2/3 inch);
F 2911 Vi
F 2911 SF: 982 mm (38 2/3 inch);
F 2912 Vi
F 2912 SF: 982 mm (38 2/3 inch);
B) Furniture front (max. 38 mm) (1 1/2 inch)
C) Door handle
D) Distance from the door to the wall (without furniture front and door handle):
F 2411 Vi
F 2411 SF
F 2471 Vi
F 2471 SF: 237 mm (9 1/3 inch);
F 2412 Vi
F 2412 SF
F 2472 Vi
F 2472 SF: 237 mm (9 1/3 inch);
F 2671 SF: 296 mm (11 2/3 inch);
F 2672 Vi
F 2672 SF: 296 mm (11 2/3 inch);
F 2811 SF
F 2811 Vi: 363 mm (14 1/3 inch);
F 2812 SF
F 2812 Vi: 363 mm (14 1/3 inch);
F 2911 Vi
F 2911 SF: 428 mm (16 7/8 inch);
F 2912 Vi
F 2912 SF: 428 mm (16 7/8 inch);
E) ONLY valid for SF versions: A + 25 mm (1 inch)
