K 2811 SF
Your exclusive advantages
MasterCool – BrilliantLight
Perfectly lit
MasterCool – DynaCool
Perfect food storage
MasterCool – MasterSensor
Convenient operation with a tap of a finger
Inside the Box
Product data sheet
| Fridge | • |
| Built-in | • |
| Built-in integrated | • |
| Door hinge side | Left |
| Convertible hinging | • |
Can be installed side-by-side Side-by-SideSelected refrigerators and freezers, for 140 cm niche hieghts and above can be installed next to each. Some freestanding appliances can also be conveniently combined together. Depending on your product selection the matching refrigerator or freezer will be listed under “side-by-side combination”. Features depend on model. Images are only examples and used for explanation purposes | • |
| Front color | Stainless steel/CleanSteel |
Lighting  MasterCool – BrilliantLightSoft and attractive: High-quality LED strips offer perfect illumination and a beautiful lighting. Features depend on model. Images are only examples and used for explanation purposes | BrilliantLight |
Freshness system  MasterCool – MasterFreshIdeal climate: Food stays fresh for up to 3 times longer due to perfect temperature and humidity. Features depend on model. Images are only examples and used for explanation purposes | MasterFresh |
DynaCool  MasterCool – DynaCoolStorage freedom: A fan ensures a uniform temperature throughout the entire unit. Features depend on model. Images are only examples and used for explanation purposes | • |
| SelfClose | • |
Push2open  MasterCool – Push2openThis appliance integrates perfectly into handleless kitchens, as the door opens by pressing the front. Features depend on model. Images are only examples and used for explanation purposes | • |
| FullAccess | • |
| EasyClean | • |
| MaxLoad hinge | • |
| Electronic temperature display and control | MasterSensor |
| Super Cooling | • |
| No. of temperature zones | 2 |
| Sabbath mode | • |
| Height-adjustable toughened glass shelves | 2 |
| No. of removable fruit and vegetable drawers | 1 |
| No. of PerfectFresh drawers | 2 |
| SlidingShelf | • |
| Door rack for tins | 1 |
| Inner door racks for bottles | 3 |
Miele@home
| • |
| WiFiConn@ct | • |
MobileControl  Features depend on model. Images are only examples and used for explanation purposes | • |
| Lock function | • |
| Overflow protection | • |
| Acoustic door alarm | • |
| Acoustic temperature alarm, freezer section | • |
| Optical door alarm | • |
| Optical temperature alarm | • |
| Niche width min in in.(mm) | 30 (762) |
| Niche width max in in.(mm) | 30 (762) |
| Niche height min in in.(mm) | 84 (2134) |
| Niche height max in in.(mm) | 85 3/16 (2164) |
| Niche depth in in.(mm) | 24 (610) |
| Appliance width in in.(mm) | 29 3/4 (756) |
| Appliance height in in.(mm) | 83 3/4 (2127) |
| Appliance depth in in.(mm) | 24 3/4 (629) |
| Weight in lbs.(kg) | 408 (185.0) |
| Fridge compartment volume in cu. ft. (l) | 16.77 (475) |
| Total usable capacity in cu. ft. (l) | 16.77 (475) |
| Current consumption in milliampere (mA) | 4 |
| Voltage in V | 120 |
| Fuse rating in A | 10 |
| Frequency in Hz | 60 |
| Wire length in ft (m) | 9 (3.0) |
Follow the link and you will find all the resources you need for planning and installing any of our products
Follow the link and you will find all the resources you need for planning and installing any of our products
Follow the link and you will find all the resources you need for planning and installing any of our products
Descriptions
Laying of cabling, MasterCool (installation drawing)
Descriptions
Opening angle 90°/115°, right side stop, MasterCool (Sketch) with footnote
A) Appliance door
F 2411 Vi
F 2411 SF
F 2471 Vi
F 2471 SF: 525 mm (20 2/3 inch);
F 2412 Vi
F 2412 SF
F 2472 Vi
F 2472 SF: 525 mm (20 2/3 inch);
K 2611 Vi
F 2671 Vi
F 2671 SF
KWT 2611 Vi
KWT 2611 SF
KWT 2671 ViS: 677 mm (26 2/3 inch);
K 2612 Vi
F 2672 Vi
F 2672 SF
KWT 2612 Vi
KWT 2612 SF
KWT 2672 ViS: 677 mm (26 2/3 inch);
K 2811 Vi
K 2811 SF
F 2811 SF
F 2811 Vi
KF 2811 Vi
KF 2811 SF: 829 mm (32 2/3 inch);
K 2812 Vi
K 2812 SF
F 2812 SF
F 2812 Vi
KF 2812 Vi
KF 2812 SF: 829 mm (32 2/3 inch);
K 2911 Vi
K 2911 SF
F 2911 Vi
F 2911 SF
KF 2911 Vi
KF 2911 SF: 982 mm (38 2/3 inch);
K 2912 Vi
K 2912 SF
F 2912 Vi
F 2912 SF
KF 2912 Vi
KF 2912 SF: 982 mm (38 2/3 inch);
B) Furniture front (max. 38 mm) (1 1/2 inch)
C) Door handle
D) Distance from the door to the wall (without furniture front and door handle):
F 2411 Vi
F 2411 SF
F 2471 Vi
F 2471 SF: 237 mm (9 1/3 inch);
F 2412 Vi
F 2412 SF
F 2472 Vi
F 2472 SF: 237 mm (9 1/3 inch);
K 2611 Vi
F 2671 Vi
F 2671 SF
KWT 2611 Vi
KWT 2611 SF
KWT 2671 ViS: 296 mm (11 2/3 inch);
K 2612 Vi
F 2672 Vi
F 2672 SF
KWT 2612 Vi
KWT 2612 SF
KWT 2672 ViS: 296 mm (11 2/3 inch);
K 2811 Vi
K 2811 SF
F 2811 SF
F 2811 Vi
KF 2811 Vi
KF 2811 SF: 363 mm (14 1/3 inch);
K 2812 Vi
K 2812 SF
F 2812 SF
F 2812 Vi
KF 2812 Vi
KF 2812 SF: 363 mm (14 1/3 inch);
K 2911 Vi
K 2911 SF
F 2911 Vi
F 2911 SF
KF 2911 Vi
KF 2911 SF: 428 mm (16 7/8 inch);
K 2912 Vi
K 2912 SF
F 2912 Vi
F 2912 SF
KF 2912 Vi
KF 2912 SF: 428 mm (16 7/8 inch);
E) ONLY valid for SF versions: A + 25 mm (1 inch)
Descriptions
Side-by-side, MasterCool, without partition wall, with heating mat (Sketch) (with footnote)
1) Heating mat KSK 2001 (EU
AUS
CN) or KSK 2002 (US
CA
MX
BR)
Descriptions
MasterCool, top view, doorway, installation drawings
