DA 3698
- Elegant design - extremely slim canopy with a width of 35 1/8 (892) in (mm)
- Unique user convenience – Con@ctivity
Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the Cooktop.
Features depend on model. Images are only examples and used for explanation purposes
- Energy-efficient and uniform illumination - 3 LED ClearView Lighting
- Energy-efficient and quiet
Your exclusive advantages
Con@ctivity
Automatic operation for intelligent blower control
Con@ctivity
Automatic operation for intelligent blower control
Active AirClean filter
A completely odor-free kitchen
Stainless-steel grease filters (10-layer)
Easy to use and effective against grease
Inside the Box
Product data sheet
| Built-in ventilation hood | • |
| Color | Stainless steel |
| Variable height available as special order | • |
| Variable width available as special order | • |
| Recirculated mode | Convertible |
| Recirculation conversion kit (order separately) | DUU 151 |
| OdorFree charcoal filter (order separately) | DKF19-1 |
| Miele@home | • |
| Electronic controls | • |
Light-touch controls  Light-touch switches with LEDThe light-touch switches with LED lighting provide special convenience. In addition to increasing and decreasing power output and switching the lighting on and off, you will find special features such as a fan run-on function or filter saturation indicator on mid-range appliances and higher. Features depend on model. Images are only examples and used for explanation purposes | • |
| Power levels (number excl. Intensive) | 3 |
| Intensive setting | • |
| Programmable Intensive switch-off | • |
| Grease filter saturation indicator | • |
Programmable grease filter saturation indicator  filter saturation indicatorEasy filter replacement: A red light lets you know when the grease and/or OdorFree charcoal filter is saturated. Features depend on model. Images are only examples and used for explanation purposes | • |
Programmable charcoal filter saturation indicator filter saturation indicatorEasy filter replacement: A red light lets you know when the grease and/or OdorFree charcoal filter is saturated. Features depend on model. Images are only examples and used for explanation purposes | • |
| Hood in Motion | • |
CleanCover  Miele CleanCoverMiele’s unique easy cleaning: The sealed, smooth surface prevents contact with the electrical components/motor. Features depend on model. Images are only examples and used for explanation purposes | • |
PowerManagement system  Power management systemThe intelligent Power management system automatically conserves energy when the cooker hood is in use without the user having to intervene. Within a predetermined time frame, power is automatically switched down to the next lowest setting. And a lower fan setting means automatically less energy consumption. Features depend on model. Images are only examples and used for explanation purposes | • |
ECO motor  Eco package"In addition, the high efficiency of cooker hoods with the ECO package ensures excellent performance as well as exemplary energy consumption:" "in comparison to conventional cooker hoods, these hoods use up to 70% less energy." Features depend on model. Images are only examples and used for explanation purposes | • |
| WiFiConn@ct | • |
Automatic function Con@ctivity 2.0 (Zigbee)  Con@ctivityOptimum room climate: The required blower output is automatically controlled by the cooktop settings. Features depend on model. Images are only examples and used for explanation purposes | • |
| Number of dishwasher-safe stainless-steel grease filters | 2 |
LED ClearView lighting  LED ClearView LightingEnvironmentally friendly and long lasting: With up to 4.5 W they illuminate the cooktop with a warm light. Features depend on model. Images are only examples and used for explanation purposes | • |
| Number x W | 3 x 3 W |
| Light intensity in Lx | 500 lx |
| Color temperature in K | 3500 Kelvin |
| Light dimmer function | • |
Dual-action blower  High-quality and powerful motorsPowerful and quiet: Radial blowers on both sides ensure high air throughput and vented with low noise levels. Features depend on model. Images are only examples and used for explanation purposes | • |
DC motor  ECO motorThe ECO motor operates with DC current and saves up 70% energy compared to conventional motors. Thanks to this technology, it operates very quietly yet as powerfully as all fans used by Miele. Features depend on model. Images are only examples and used for explanation purposes | • |
Safety shut-off  Safety turn offSensible, even in case of operating errors: The ventilation hood will switch off automatically after 10 hours. Features depend on model. Images are only examples and used for explanation purposes | • |
| Canopy width in in. (mm) | 35 1/8 (892) |
| Canopy height in in. (mm) | 1 1/2 (37) |
| Depth of hood canopy in in. (mm) | 12 1/4 (309) |
| Minimum distance above electric cooktops in in. (mm) | 24 1/8 (610) |
| Minimum height above gas cooktop (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm | 26 (660) |
| Net weight in lbs. (kg) | 42 (19.0) |
| Length of electrical wire in ft. (m) | 4 (1.5) |
| Standard plug fitted | • |
| Total connected load in kW | 0.36 |
| Voltage in V | 120 |
| Fuse rating in A | 15 |
| Frequency in Hz | 60 |
| Number of phases | 1 |
| Vent connection at top | • |
| Vent connection at rear | • |
| Vent connection at top and rear | • |
| Diameter of vent connection in in. (mm) | 6 (150) |
| Combination with WiFi-enabled Miele cooktop Features depend on model. Images are only examples and used for explanation purposes | required |
Optional products and accessories
Follow the link and you will find all the resources you need for planning and installing any of our products
Follow the link and you will find all the resources you need for planning and installing any of our products
Descriptions
DA 3698 (Installation drawing)
1. Vented
recirculation with DUU 150.
2. Housing unit carcase is 38 mm shorter than the door.This also applies to adjacent cabinets when the appliance is installed in a 600 mm wide housing unit.
3. Installation is also possible in a 60 cm wide housing unit.In this case
the door of the housing unit must open upwards (top-hinged) to enable access to grease filters. This also applies to adjacent cabinets.
4. Vent connection alternatively to the rear.
5. After the wall unit has been installed
a partition can be fitted. The slots for grease filters and odour-absorbing filters for use in recirculation mode must be accessible.
6. Alternatively
side sectiions can be added to the wall unit.
In regard to dimenions for wall unit height and cut-outs
fitted accessories should be taken into account (e.g. silencers
XKM module).
Descriptions
DA 3698, DA 3698 EXT (Installation drawing) - US
1. Vented
recirculation with DUU 150.
2. Housing unit carcase is 38 mm shorter than the door.This also applies to adjacent cabinets when the appliance is installed in a 600 mm wide housing unit.
3. Installation is also possible in a 60 cm wide housing unit.In this case
the door of the housing unit must open upwards (top-hinged) to enable access to grease filters. This also applies to adjacent cabinets.
4. Vent connection alternatively to the rear.
5. After the wall unit has been installed
a partition can be fitted. The slots for grease filters and odour-absorbing filters for use in recirculation mode must be accessible.
6. Alternatively
side sectiions can be added to the wall unit.
In regard to dimenions for wall unit height and cut-outs
fitted accessories should be taken into account (e.g. silencers
XKM module).
- Subject to technical changes; no liability accepted for the accuracy of the information given.
