HR 1134-1 G
36 inch range All Gas with DirectSelect, Twin convection fans and M Pro dual stacked burners
- Subject to technical changes; no liability accepted for the accuracy of the information given.
Your exclusive advantages
Self Clean Oven and Self Clean Ready Accessories
Treat yourself to minimum effort
Less cleaning effort: The grease residue is broken down, helping to keep the oven and cooking accessories clean.
Rapid PreHeat
Your guarantee for perfect results
For those who lead a busy life: If there's not much time for cooking, you will really appreciate this program.
Self-cleaning and PyroFit
Treat yourself to minimum effort
Less cleaning effort: Automatic self-cleaning of the cooking compartment and accessories at high temperatures.
Features depend on model – images are only examples and used for explanation purposes
Maintenance (4)
Self Clean Oven and Self Clean Ready Accessories
Treat yourself to minimum effort
Less cleaning effort: The grease residue is broken down, helping to keep the oven and cooking accessories clean.
ComfortClean Dishwasher-Safe Grates
Efficiently protects and makes cleaning easier
Fast cleaning: Remove the pot rests and wash in the dishwasher. Fast clean-up with dishwasher-safe grates.
Self-cleaning and PyroFit
Treat yourself to minimum effort
Less cleaning effort: Automatic self-cleaning of the cooking compartment and accessories at high temperatures.
Clean Touch Steel™Front
Protection for immaculate stainless steel surfaces
No fingerprints on stainless steel: surface has special finish which keeps clean without special cleaning agents.
User convenience (3)
Individual settings
Appliance configuration according to your wishes
You decide: Language, buzzer tones, display brightness and much more can be individually adjusted.
Timer Function
Leave time management to your oven
Always on time: The start time, finish time and duration of the cooking process are easy to select.
Soft Open and Soft Close
Everything is well thought through
The Range oven door effortlessly opens and closes, preventing the door from shutting or slamming.
Efficiency and sustainability (1)
Residual Heat Utilization
Conserve heat and energy
Ecological and economical: Miele ovens turn off early and use residual heat to complete the cooking process.
Oven cabinets (2)
Rapid PreHeat
Your guarantee for perfect results
For those who lead a busy life: If there's not much time for cooking, you will really appreciate this program.
TwinPower Convection Blowers and Power Convection Blower
Reaches the desired temperature very quickly
Quickly ready for use: Two hot air blowers provide very rapid heating-up of the oven and optimum hot air distribution
Safety (2)
Cooling System and Cool-Touch Fronts
Pleasantly cool surfaces
Maximum protection: All surfaces on and around the appliance remain cool and can be touched safely.
Safety functions
Automatic switch-off for maximum safety
Your guardian angel: If you forget to switch off the appliance, the safety switch-off steps in for you.
Operating modes (4)
Convection Bake
Superbly light and fluffy: Ideal for quick, gentle baking and roasting on several levels.
Convection Roast
Crispy on the outside, succulent inside: Ideal for chicken, duck, joints, rolled meat and many other meat dishes.
Bake
Individual requirements: For dishes which need to be cooked in a bain marie or browned from below.
Maxi Broil
Versatile function for indoors: For grilling large quantities of steak, sausages, kebabs, etc.
Product data sheet
Type of heating
| All gas | • |
| Gas type | Natural gas |
Construction type
| Range | • |
| Appliance width in inches | 36 |
Operating modes
| Defrost | • |
| MasterChef automatic programs | No |
| MasterChef Plus automatic programs | No |
| Maxi Broil | • |
| Convection Bake | • |
| Bake | • |
| Convection Roast | • |
Design
| Appliance color | Clean Touch Steel |
| Oven display | DirectSelect |
Cooktop features
| Number of gas burners | 6 |
| Number of TrueSimmer burners x power in BTU | 1 x 8.000 |
| Number of power burners x power in BTU | 2 x 9.000 |
| Number of high burners x power in BTU | 3 x 19.500 |
| True Simmer function | • |
| GasStop | • |
Control panel
| Precision knobs | • |
| Time of day display | • |
| Minute minder | • |
| Time buffer in h | • |
| Automatic switch-off | • |
| Programmable cooking time | • |
| Acoustic signal when desired temperature is reached | • |
| Favorites | No |
| Individual settings | • |
Door
| CleanGlass door | • |
| Door contact switch | • |
| SoftClose oven door/ SoftOpen | • |
Cavity
| Oven cavity volume in cu. ft. (l) | 5.76 (163) ft³ (l) |
| Number of oven shelf levels | 6 |
| No. of halogen lamps | 2 |
| TwinPower hot air fans | • |
Efficiency and sustainability
| Residual heat utilization | • |
Cleaning convenience
| Stainless-steel front with partial Clean Touch Steel finish | • |
| Oven with self-cleaning program | • |
| ComfortClean dishwasher-safe grates | • |
| Cooktop surface | Black enamel |
Safety
| Appliance cooling system with cool touch front | • |
| Safety cut-out | • |
| System lock | • |
| Door contact switch | • |
| Door lock during self cleaning | • |
Technical data
| Appliance width in inches | 35 15/16 |
| Appliance width in in.(mm) | 36 1/8 (915) |
| Appliance height min in in.(mm) | 37 1/8 (942) |
| Appliance height max in in.(mm) | 38 5/8 (980) |
| Appliance depth in in. (depth) with bullnose | 27 1/2 (698) |
| Electric total rated load in kW | 0.60 |
| Power Rating in V | 120 |
| Fuse rating in A | 15 |
| Number of phases | 1 |
Inside the Box
- PerfectClean universal baking tray (1)
- Self Clean ready baking and roasting rack (1)
- Self clean ready baking and roasting racks with rail system (1)
- Side racks self clean ready (1)
- Side racks self clean ready (1)
Optional products and accessories
Downloads, CAD, & apps
- Warranty conditionsPDF
- Operating and Installation instructionsPDF
- Operating instructions/Installation instructionsPDF
- Operating instructions/Installation instructionsPDF
- Product sheetPDF
Follow the link and you will find all the resources you need for planning and installing any of our products
- dwgZIP
- fbxZIP
- rvtZIP
- ifcZIP
- rfaZIP
Follow the link and you will find all the resources you need for planning and installing any of our products
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorized experts. In the event of queries, please call us for some no-obligation advice!
Descriptions
HR 11xx (Installation drawing)
(x) = Toe-kick height adjustment 5" - 6 1/2" (127 mm - 165.1 mm)
Descriptions
HR 11xx (Installation drawing)
Descriptions
HR1134 (installation drawing)
E = Electric connection
G = Gas connection
Descriptions
HR1134 (installation drawing)
(x) = Toe-kick height adjustment 5" - 6 1/2" (127 mm - 165.1 mm)
Descriptions
H1xxx installation drawings
1 29 11/16" / 754 mm
2 23 3/4" / 603
6 mm
3 2 5/8" / 66
5 mm
4 1 11/16" / 43 mm
5 1 11/16" / 42
5 mm
